Multiple piping type _ 7
MULTI ZONEMULTI ZONE
Part 2 Product data_Outdoor units
Models : MR36TQY3JMA
Cooling
n Mixed type indoor unit
Note :
1. Capacities are based on the following conditions:
Cooling: - Indoor Temperature 26.7°C (80°F) DB / 19.4°C (67°F) WB
- Outdoor Temperature 35°C (95°F) DB / 23.9°C (75°F) WB
Heating: - Indoor Temperature 21.1°C (70°F) DB / 15.6°C (60°F) WB
- Outdoor Temperature 8.3°C (47°F) DB / 6.1°C (43°F) WB
Piping Length - Interconnecting Piping Length 7.6m (25ft)
- Level Difference of Zero
2. Wiring cable size must comply with the applicable local and national codes.
3. The specification may be subject to change without prior notice for purpose of
improvement.
4. Maximum sum of connected indoor units capacity is 48 kBtu/h.
5. At least two indoor units should be connected.
Combination of
Indoor Unit (kBtu/h Class)
Room Capacity
Total Capacity
Input(W)
EER SEER
Min Rated Max
UNIT UNIT-A UNIT-B UNIT-C UNIT-D Total
UNIT-A
(Btu/h)
UNIT-B
(Btu/h)
UNIT-C
(Btu/h)
UNIT-D
(Btu/h)
Btu/h kW Btu/h kW Btu/h kW Min Rated Max
9 9 - - 18 8,438 8,438 - - 10,125 3.0 16,875 4.9 18,731 5.5 1,225 1,750 2,449 9.6 16.2
9 12 - - 21 8,438 11,250 - - 11,813 3.5 19,688 5.8 21,853 6.4 1,403 2,004 2,805 9.8 16.5
12 12 - - 24 11,250 11,250 - - 13,500 4.0 22,500 6.6 24,975 7.3 1,552 2,217 3,104 10.1 17.0
9 18 - - 27 8,438 16,875 - - 15,188 4.5 25,313 7.4 28,097 8.2 1,723 2,462 3,446 10.3 17.2
12 18 - - 30 11,250 16,875 - - 16,875 4.9 28,125 8.2 31,219 9.1 1,873 2,675 3,745 10.5 17.6
18 18 - - 36 15,000 15,000 - - 18,000 5.3 30,000 8.8 33,300 9.8 1,965 2,807 3,930 10.7 17.9
9 9 9 - 27 8,438 8,438 8,438 - 15,188 4.5 25,313 7.4 29,109 8.5 1,638 2,339 3,275 10.8 18.1
9 9 12 - 30 8,438 8,438 11,250 - 16,875 4.9 28,125 8.2 32,344 9.5 1,752 2,502 3,503 11.2 18.9
9 12 12 - 33 8,182 10,909 10,909 - 18,000 5.3 30,000 8.8 34,500 10.1 1,837 2,624 3,674 11.4 19.2
9 9 18 - 36 7,500 7,500 15,000 - 18,000 5.3 30,000 8.8 34,500 10.1 1,837 2,624 3,674 11.4 19.2
12 12 12 - 36 10,000 10,000 10,000 - 18,000 5.3 30,000 8.8 34,500 10.1 1,837 2,624 3,674 11.4 19.2
9 12 18 - 39 6,923 9,231 13,846 - 18,000 5.3 30,000 8.8 34,500 10.1 1,837 2,624 3,674 11.4 19.2
12 12 18 - 42 8,571 8,571 12,857 - 18,000 5.3 30,000 8.8 34,500 10.1 1,837 2,624 3,674 11.4 19.2
9 18 18 - 45 6,000 12,000 12,000 - 18,000 5.3 30,000 8.8 34,500 10.1 1,837 2,624 3,674 11.4 19.2
12 18 18 - 48 7,500 11,250 11,250 - 18,000 5.3 30,000 8.8 34,500 10.1 1,837 2,624 3,674 11.4 19.2
9 9 9 9 36 7,500 7,500 7,500 7,500 18,000 5.3 30,000 8.8 36,000 10.6 1,752 2,503 3,505 12.0 20.1
9 9 9 12 39 6,923 6,923 6,923 9,231 18,000 5.3 30,000 8.8 36,000 10.6 1,752 2,503 3,505 12.0 20.1
9 9 12 12 42 6,429 6,429 8,571 8,571 18,000 5.3 30,000 8.8 36,000 10.6 1,752 2,503 3,505 12.0 20.1
9 9 9 18 45 6,000 6,000 6,000 12,000 18,000 5.3 30,000 8.8 36,000 10.6 1,752 2,503 3,505 12.0 20.1
9 12 12 12 45 6,000 8,000 8,000 8,000 18,000 5.3 30,000 8.8 36,000 10.6 1,752 2,503 3,505 12.0 20.1
9 9 12 18 48 5,625 5,625 7,500 11,250 18,000 5.3 30,000 8.8 36,000 10.6 1,752 2,503 3,505 12.0 20.1
12 12 12 12 48 7,500 7,500 7,500 7,500 18,000 5.3 30,000 8.8 36,000 10.6 1,752 2,503 3,505 12.0 20.1
2 UNIT
3 UNIT
4 UNIT
3. Combination table
