PERFORMANCE DATA FOR 2009, 2008 MODELS
9
COOLING
PERFORMANCE DATA*
EVAP. AIR TEMP. DEG. F
CONDENSER
TEMPERATURE DEG. F
Discharge Temp Suction Temp Super Heat Sub-Cooling
OPERATING PRESSURES ELECTRICAL RATINGS R-22 REF.
Voltage
BREAKER FUSE
Discharge Air
Temp.
Drop F.
Suction Discharge Amps Cool Amps Heat
Locked Rotor
Amps
Charge in
OZ.
60 Hertz Amps
Q-Chassis
XQ05L10A-C 56 24 119 151 58 13 20 89 255 4.9 28.0 21.4 115 15
XQ06L10A-C 55 26 121 157 65 13 27 87 261 5.0 24.0 21.0 115 15
XQ08L10A-B 52 29 128 167 60 13 33 81 283 6.8 36.2 22.1 115 15
XQ08L10A-E 52 29 125 161 49 13 24 81 280 6.7 36.2 19.8 115 15
XQ10L10A-C 50 31 130 176 65 20 29 75 287 9.2 44.0 19.2 115 15
XQ12L10A-B 51 29 126 166 51 6 30 75 271 11.0 56.0 31.0 115 15
XQ12L10A-C 51 29 126 166 51 6 30 75 271 11.0 56.0 31.0 115 15
EQ08L11A-B 52 29 124 173 69 21 29 82 283 6.5 10.7 36.2 20.0 115 15
EQ08L11A-E 52 29 125 161 49 13 24 81 280 6.7 10.7 36.2 19.8 115 15
S-Chassis
SS08L10-E 56 24 116 157 68 16 18 86 250-260 6.6 36.2 27.0 115 15
SS08L10-F 56 24 116 157 68 16 18 86 250-260 6.6 36.2 27.0 115 15
SS08L10-G 53 24 116 157 57 13 23 85 250-260 6.5 36.2 27.0 115 15
SS10L10-D 57 23 117 166 65 16 23 82 243 7.5 42.0 26.0 115 15
SS10L10-E 57 23 117 166 65 16 23 82 243 7.5 42.0 26.0 115 15
KS12L10-E 52 28 122 170 60 12 26 83 266 9.0 44.0 30.0 115 15
KS12L10-F 52 28 122 170 60 12 26 83 266 9.0 44.0 30.0 115 15
SS12L10-E 53 27 124 169 62 13 30 82 266 9.3 44.0 32.0 115 15
SS12L10-F 53 27 124 169 62 13 30 82 266 9.3 44.0 32.0 115 15
KS15L10-C 51 30 125 182 62 16 29 77 278 12.2 61.0 29.0 115 15
KS15L10-D 51 30 125 182 62 16 29 77 278 12.2 61.0 29.0 115 15
SS14L10-D 53 27 125 184 62 15 27 78 268 12.3 61.0 29.2 115 15
SS14L10-E 53 27 125 184 62 15 27 78 268 12.3 61.0 29.2 115 15
SS12L30-E 58 22 122 174 66 17 28 84 261 4.7 21.0 31.0 208 / 230 15
SS12L30-F 58 22 122 174 66 17 28 84 261 4.7 21.0 31.0 208 / 230 15
SS16L30-D 50 31 130 176 53 8 35 77 279
7.9 35.0 32.1 208 / 230 15
SS16L30-E 50 31 130 176 53 8 35 77 279 7.9 35.0 32.1 208 / 230 15
ES12L33-D 58 22 122 174 66 17 28 84 261 4.7 15.1 21.0 31.0 208 / 230 20
ES12L33-E 58 22 122 174 66 17 28 84 261 4.7 15.1 21.0 31.0 208 / 230 20
ES16L33-C 49 32 130 179 50 8 34 75 279 7.4 15.1 35.0 32.0 208 / 230 20
ES16L33-D 49 32 130 179 50 8 34 75 279 7.4 15.1 35.0 32.0 208 / 230 20
YS09L10-F 64 16 116 164 71 20 19 87 249 7.4 7.0 44.0 28.0 115 15
YS09L10-G 64 16 116 164 71 20 19 87 249 7.4 7.0 44.0 28.0 115 15
YS13L33-D 51 29 122 172 65 18 30 80 269 5.5/5.1 5.7/5.3 24.0 32.0 1 20
YS13L33-E 51 29 122 172 65 18 30 80 269 5.5/5.1 5.7/5.3 24.0 32.0 1 20
M-Chassis
KM24L30-C 50 31 132 187 56 14 37 70 287 11.2 68.0 53.0 208 / 230 20
KM24L30-D 50 31 132 187 56 14 37 70 287 11.2 68.0 53.0 208 / 230 20
YM18L34-D 61 19 126 187 67 24 28 73 280 9.2/8.75 8.8/8.3 41.0 43.0 208/230 30
YM18L34-E 61 19 126 187 67 24 28 73 280 9.2/8.75 8.8/8.3 41.0 43.0 208/230 30
EM18L34-C 49 31 125 175 63 21 31 72 271 8.1 18.9 42.0 39.5 208 / 230 15
KM18L30-C 49 31 125 175 63 21 31 72 271 8.1 42.0 39.5 208 / 230 15
KM18L30-D 49 31 125 175 63 21 31 72 271 8.1 42.0 39.5 208 / 230 15
SM18L30A-D 54 26 121 171 61 13 25 81 262 7.7/7.1 37.0 45.0 208/230 15
SM18L30A-E 54 26 121 171 61 13 25 81 262 7.7/7.1 37.0 45.0 208/230 15
SM21L30-E 48 32 125 173 52 13 25 75 278 9.6/9.3 43.0 43.0 208/230 15
SM21L30-F 48 32 125 173 52 13 25 75 278 9.6/9.3 43.0 43.0 208/230 15
EM24L34-B 50 31 132 187 56 14 37 70 287 11.2 25.0 68.0 53.0 208 / 230 30
SM24L30-C 50 31 132 187 56 14 37 70 287 11.2 68.0 53.0 208 / 230 20
SM24L30-D 50 31 132 187 56 14 37 70 287 11.2 68.0 53.0 208 / 230 20
L-Chassis
SL28L30-D 53 28 128 172 56 13 29 73 259 13.0 68.0 50.1 208 / 230 20
SL28L30-E 53 28 128 172 56 13 29 73 259 13.0 68.0 50.1 208 / 230 20
SL36L30A-D 49 31 133 192 53
12 37 70 287 17.2 91.0 57.6 208 / 230 30
SL36L30A-E 49 31 133 192 53 12 37 70 287 17.2 91.0 57.6 208 / 230 30
EL36L35A-D 49 32 133 194 53 13 38 70 302 18.0 25.0 91.0 60.0 208 / 230 30
EL36L35A-E 49 32 133 194 53 13 38 70 302 18.0 25.0 91.0 60.0 208 / 230 30
YL24L35-E 52 28 124 175 65 22 29 74 268 11.9/11.1 11.7/11.0 68.0 73.0 208/230 30
YL24L35-F
52 28 124 175 65 22 29 74 268 11.9/11.1 11.7/11.0 68.0 73.0 208/230 30
*Rating Conditions: 80 degrees F, room air temp. & 50% relative humidity, with 95 degree F, outside air temp & 40% relative humidity, all systems use R22.
