Friedrich racservmn - Unit Performance

5
PERFORMANCE R-22 BREAKER
DATA* REFRIG. FUSE
Cooling Discharge Temp. Suction Discharge Amps Locked Charge in 60 Hertz
Air Drop F. Rotar Amp OZ. Amps
EQ08J11-A 50.5 29.5 72 262 7.5 39.2 20 15
EQ08J11-B 50.5 29.5 74 259 7.5 39.2 20 15
DATA* R-22 BREAKER
Cooling REFRIG. FUSE
Discharge Temp. Suction Discharge Amps Locked Charge in 60 Hertz
Air Drop F. Rotar Amp OZ. Amps
XQ05J10B 55.45 24.55 79 245 4.6 34 20 15
XQ06J10-A 51.45 28.55 82 262 5.1 35 21 15
XQ06J10-B 51.45 28.55 79 254 5.1 35 21 15
XQ07J10-1 52.22 27.95 77 250 6.5 37 24 15
XQ08J10-1 50.5 29.5 72 262 4.5 38 20 15
XQ08J10-A 50.5 29.5 72 262 4.5 38 21 15
PERFORMANCE EVAPORATOR AIR ELECTRICAL R-22 BREAKER
DATA* TEMP. DEG. F. RATINGS REFRIG. FUSE
Cooling Discharge Temp. Suction Discharge Amps Locked Charge in 60 Hertz
Air Drop F. Rotar Amp OZ. Amps
SQ05J10B-B 55.45 24.55 79 245 4.4 34.'0 16.'0 15
SQ06J10B-A 51.45 28.55 82 262 5.2 35.'0 15.7 15
SQ06J10B-B 51.45 28.55 79 254 5.2 35.'0 15.7 15
SQ08J10C-1 50.5 29.5 72 262 7.5 39.2 19.5 15
PERFORMANCE R-22 BREAKER
DATA* REFRIG. FUSE
Cooling Discharge Temp. Suction Discharge Amps Locked Charge in 60 Hertz
Air Drop F. Rotar Amp OZ. Amps
KQ05J10B-B 56.34 28.66 73 251 5.2 29.'0 15.'0 15
KQ05E10-B 56.34 28.66 79 245 5.2 29.'0 15.'0 15
KQ05E10-C 56.34 28.66 79 245 5.2 29.'0 15.'0 15
KQ06J10B-A 58.02 21.98 82 262 5.8 35.'0 15.'0 15
KQ06J10B-B 58.02 21.98 80 269 5.8 35.'0 19.'0 15
KQ06E10-A 58.02 21.98 82 262 5.8 35.'0 15.'0 15
KQ06E10-B 58.02 21.98 79 254 5.8 35.'0 15.'0 15
YQ06J10B-A 54.1 25.9 81 267 5.7 39.2 19.'0 15
*Rating Conditions: 80 degree F. Room Air Temperature and 50% Relative Humidity with
95 degree F. Outside Air Temperature and 40% Relative Humitidy
ELECTRICAL
TEMP. DEG. F. PRESSURES RATINGS
EVAPORATOR AIR OPERATING
KQ-YQ PERFORMANCE DATA
SQ PERFORMANCE DATA
EQ PERFORMANCE DATA
EVAPORATOR AIR OPERATING ELECTRICAL
ELECTRICAL
RATINGS
EVAPORATOR AIR
TEMP. DEG. F.
OPERATING
PRESSURES
OPERATING
PRESSURES
XQ PERFORMANCE DATA
TEMP. DEG. F. PRESSURES RATINGS
