10
PERFORMANCE DATA *YS09J10B-A **YS12J33-A **YM18J34A-A **YL24J35C-A
(Heating)
AHAM @ 70°F Inside 47°F Outside 8300 12400/12300 17200/17200 23000/22800
@ 70°F Inside 35°F Outside 10700/8900 13000/10600 17300/14300
Evaporator Air Temperature Rise
@ 70°F Inside 47°F Outside 19.62 31.38 24.74 31.71
@ 70°F Inside 35°F Outside 28.69/23.87 24.46/20.22 24.38/20.16
AMPS @ 70°F Inside 47°F Outside 6.7 6.0/6.5 8.5/9.0 10.4/11.5
@ 70°F Inside 35°F Outside 16.0/14.7 19.5/17.0 24.0/22.4
Watts @ 70°F Inside 47°F Outside 760 1340/1300 1880/1820 2350/2340
@ 70°F Inside 35°F Outside 3500/2900 5500/4650 5500/4650
Suction/Head PSIG
@ 70°F Inside 47°F Outside 53.5/222 52.5/251 53/225 54/236.5
* Do not operate below 37° ambient.
** Heating element comes on at 35°F outside ambient and compressor shuts off.
SPECIFICATIONS SC06H10E
BTUH (Cooling) 5950
E.E.R. (Cooling) 8.0
Volts 115
Amperes (Cooling) 6.8
Total Watts (Cooling) 760
Hertz 60
Fuse/Breaker Size 15
Fan RPM 1595
Evaporator Air CFM 125
Dehumidification Pts/Hr 2.0
Width 1411/16"
Height 1013/16"
Depth 27"
Minimum Ext. Into Room 2½"
Minimum Ext. To Outside 15½"
Net Weight 70
Shipping Weight 80
PERFORMANCE DATA* SC06H10E
DISCHARGE 56.1
EVAPORATOR AIR AIR
TEMP. °F TEMP 23.9
DROP °F
OPERATING SUCTION 72
PRESSURES DISCHARGE 293
AMPS 6.8
ELECTRICAL
RATINGS LOCKED 35.0
ROTOR AMPS
R-22 CHARGE IN 14
REFRIG. OUNCES
COMP. CHARGE IN 9.8
OIL FLUID OZ.
* Rating Conditions:
80°F Room Air Temperature and 50% Relative Humidity with
95°F Outside Air Temperature at 40% Relative Humidity.
