PERFORMANCE R-22 BREAKER
DATA* REFRIG. FUSE
Cooling Discharge Temp. Suction Discharge Amps Locked Charge in 60 Hertz
Air Drop F. Rotar Amp OZ. Amps
WS07A10E-B 59.5 19.5 84 300 7.'0 32 19 15
WS07A10E-C 59.5 19.5 85 299 7.'0 32 28 15
WS07A10E-D 59.5 19.5 85 299 7.'0 32 20 15
WS10A10-A 58 22 83 307 9.8 48 25 15
WS10A10-B 58 22 83 307 9.8 48 26 15
WS12A10E-B 55 25 81 290 11.9 54 28.5 15
WS13A10-A 55 25 79 281 12 55 36 15
WS09A30E-B 58 22 86 302 4.7 44 22 15
WS12A30E-A 47.1 32.9 80 308 11.9 54 27.5 15
WS12A30E-B 46 33 80 305 11.9 54 42 15
WS15A30-A 47 33 72 310 8.5 42 43.5 15
DATA* R-22 BREAKER
Cooling REFRIG. FUSE
Discharge Temp. Suction Discharge Amps Locked Charge in 60 Hertz
Air Drop F. Rotar Amp OZ. Amps
WE09A33E-C 58 22 86 302 4.7 44 23 20
WE12A33E-B 55 25 80 308 6.5 54 27.5 20
WE15A33-A 47.1 32.9 71 310 8.5 42 43.5 20
WY09A33F-A 58 22 83 288 4.3 44 24 20
WY12A33G-A 55 25 81 295 6.2 54 37 20
PERFORMANCE Heat Rise
DATA heating
WE15A33-A 40 16.2
WE09A33E-C 39 14.7
WE12A33E-B 36 14.7
* Rating Conditions: 80 degree F. Room Air Temperature and 50% Relative Humidity
95 degree F. Outside Air Temperature at 40% Relative Humidity
WS PERFORMANCE DATA
WE-WY PERFORMANCE DATA
EVAPORATOR OPERATION ELECTRICAL
ELECTRICAL
RATINGS
EVAPORATOR AIR
TEMP. DEG. F.
OPERATING
PRESSURES
TEMP. DEG. F. PRESSURES RATINGS
