PERFORMANCE R-22 BREAKE
R
DATA* REFRIG. FUSE
Cooling Discharge Temp. Suction Discharge Amps Locked Charge in 60 Hertz
Air Drop F. Rotar Amp OZ. Amps
ES12J33B-A 58 22 82 265 5.76.6 26.3 28 20
ES16J33A-A 53 27 77 269 7.5/8.0 42.'0 30 20
EM18J34B-A 55 25 71 267 8.6/9.2 42.'0 40.5 30
EL25J35-A 55 25 75 284 11.5/12.6 61.'0 48.5 30
EL35J35-A 52 28 72 317 18/20 94.'0 60 30
EL35J35-B 52 28 72 317 18/20 94.'0 60 30
PERFORMANCE Heat Rise
DATA heating
ES12J33B-A 30.5 16/14.7
ES16J33A-A 30.5 16/14.7
EM18J34B-A 28.3 19.5/17
EL25J35-A 28.6 24/22/4
EL35J35-A 22.9 24/22.4
EL35J35-B 22.9 24/22.4
DATA* R-22 BREAKER
Cooling REFRIG. FUSE
Discharge Temp Amps Locked Charge in 60 Herts
Air Drop F. Rotar Amp OZ. Amps
KS10E10-A 61 19 82 248 9.1 48.3 26.08 15
KS10J10-B 61 19 80 263 9.1 48.3 26.88 15
KS12E10-A 57 23 83 271 10.8 54.'0 28 15
KS12J10B-A 57 23 84 268 10.8 54.'0 28 15
KS15J10-A 55.78 23.52 77 279 12.'0 67.'0 29.5 15
KS12J30B-A 57 23 76 285 6.2 26.'0 30.08 15
KS18J30-A 56 24 72 293 8.7 48 48 15
KM20J30-A 55 24 70 279 9.9 48 48 15
KM24J30-A 55 25 68 301 15.'0 71.'0 54.08 15
* Rating Conditions: 80 degree F. Room Air Temperature and 50% Relative Humidity with
95 degree F. Outside Air Temperature at 40% Relative Humidity.
KS-KM PERFORMANCE DATA
EVAPORATOR AIR OPERATING ELECTRICAL
ELECTRICAL
RATINGS
EVAPORATOR AIR
TEMP. DEG. F.
OPERATING
PRESSURES
TEMP. DEG. F. PRESSURES RATINGS
