100 PB
PARTS CATALOG
24K 265V Control Box
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 80032802 ASSY CONTROL BOX VPAK 24 XL
265V
ALL 1
2 61600532 STAND OFF - PCB DIA .125 ALL 4
3 61080703 CAPCTR 40 MF 450V 2.0" X 3.75" ALL 1
4 20709185 CLAMP, CAPACITOR ALL 1
5 80118601 CONTACTOR 240VAC HCL-
1NU01AAC
ALL 1
6 61643311 RELAY 230V COIL DPDT 30A
208/240VAC
ALL 1
7 62601009 KIT E-CNTL SERV COOL HP VHA ALL 1
8 80032805 BRACKET E-CTRL VPAK 24 XL ALL 1
9 61773324 SWITCH CIRCUIT BRKR 20A 230V
CITR220Q2NS
ALL 1
10 62600601 DISPLAY SERVICE VPAC KUHL ALL 1
11 61670803 TRANSFORMER IN 265V OUT
235V
ALL 1
12 80007600 NONFUSED DISCONNECT ALL 1
13 61776111 FUSE BLOCK 3 POLES 30 AMP ALL 1
14 61773317 FUSE 600V 20A CC TD ALL 1
15 61773319 FUSE 600V 15A CC TD ALL 2
16 80106975 CONTROL BLOWER MTR PSC
ESM14165
ALL 1
17 80117001 LOCK MECHANISM BALL BEARING ALL 1
18 61610400 PIN HINGE ALL 1
19 80015707 COVER CONTROL BOX DOOR ALL 1
20 90603405 SCREW 4F-40X3/8 ROUND PAN
PHILL ZIN
ALL 1
21 80086100 KNOB KNURLED ALL 1
22 90605602 SCREW PHILLIPS #10-32 X .250 ALL 1
24 91201202 RIVET ID .093 PLASTIC ALL 1
25 80032807 CTRL BOX LID VPAK 24 XL 265V
20GA PREPAINTED
ALL
1
-26 62600203 SENSOR ID R/A TEMPERATURE
(WHITE)
ALL
1
-27 62600205 SENSOR ID COIL TEMPERATURE
(GREEN)
ALL 1
-28 62600206 SENSOR OD COIL TEMPERATURE
(BLUE)
ALL 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
Figure 913
To Next Page
