14 PB
SPECIFICATIONS
24K Dimensions
Figure 204 24K Chassis Specs)
UNIT TOP VIEW DIMENSIONS
46 23/32
51 7/8
1 1/2
44
2 1/2
CONDENSER
INLET
AIR
CONDENSER
AIR
EXHAUST
FRONT
SIDE
REAR
6 55/64 DUCT
1 DUCT
ENTRY
ELECTRICAL
BOTH SIDES
AIR
RETURN
15 7/16
31 9/32
5 5/32
20 5/8 DUCT
SUPPLY
AIR
3 55/64
1 1/2
12 19/64
1 1/2
6 55/64
20 5/8
