12 PB
SPECIFICATIONS
Chassis Specications 9K, 12K
DUC T
DIAMETER
SUPPLY
AIR
CONDEN SE R
INLET AIR
CONDENSER
AIR
EXHAUST
RETURN
AIR
SideFront Rear
23 1/8”
10”
2 15/16”
29 1/2”
29 1/2”
1 1/2”
23 1/8”
1/8” 10
1/2”
31”
19
UNIT TOP VIEW DIMENSIONS
O utside Wall
Figure 202 (9-12K Chassis Specs)
