SPECIFICATIONS
Electrical Data
MODEL 9K 12K
HEATER WATTS 2050-2500 2780-3400 4090-5000 2050-2500 2780-3400 4090-5000
VOLTAGE 208-230
ELECTRIC HEATING BTU 7000-8500 9500-11600 13900-17000 7000-8500 9500-11600 13900-17000
ELEC. HEATING CUR-
RENT (AMPS)
11.1-12.0 14.6-16.0 20.9-22.9 11.1-12.0 14.6-16.0 20.9-22.9
MINIMUM CIRCUIT
AMPACITY
15 20.0 29.2 15 20.0 29.2
BRANCH CIRCUIT FUSE
(AMPS)
15 20 30 15 20 30
LRA - COMPRESSOR
(AMPS)
21.0 21.0 21.0 23.0 23.0 23.0
BASIC HEATER SIZE 2.5 KW 3.4 KW 5.0 KW 2.5 KW 3.4 KW 5.0 KW
POWER CONNECTION HARD WIRED
RECOMMENDED
BRANCH CIRCUIT WIRE
SIZES* AWG-AMERI-
CAN WIRE GAUGE
14 12 10 12 12 10
Figure 205 (9&12K 208/230V Electrical Data)
Figure 206 (9&12K 265 Electrical Data)
MODEL 9R 12R
HEATER WATTS 2500 3400 5000 2500 3400 5000
VOLTAGE 265
ELECTRIC HEATING BTU 8500 11600 17000 8500 11600 7000
ELEC. HEATING CUR-
RENT (AMPS)
10.5 13.9 19.9 10.5 13.9 19.9
MINIMUM CIRCUIT
AMPACITY
13.8 18.0 25.7 13.8 18.0 25.7
BRANCH CIRCUIT FUSE
(AMPS)
15 20 30 15 20 30
LRA - COMPRESSOR
(AMPS)
21.0 21.0 21.0 23.0 23.0 23.0
BASIC HEATER SIZE 2.5 KW 3.4 KW 5.0 KW 2.5 KW 3.4 KW 5.0 KW
POWER CONNECTION HARD WIRED
RECOMMENDED
BRANCH CIRCUIT WIRE
SIZES* AWG-AMERI-
CAN WIRE GAUGE
14 12 10 12 12 10
