77 PB
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 80048057 CONDENSER COIL COIL
VCS.375X3X18RC2V45B19X17H3
VHA12K25RTP, VHA12K34RTP, VHA12K50RTP,
VHA12R25RTP, VHA12R34RTP, VHA12R50RTP,
1
1 80101265 CONDENSER COIL
VCS .250X4X16XC9K45A17X15H3
VHA09K25RTP, VHA09K34RTP, VHA09K50RTP,
VHA09R25RTP, VHA09R34RTP, VHA09R50RTP,
1
2 80023703 BASEPAN VPAK ALL 1
3 80044909 ASSY TUBE CHECK VALVE VHA09K25RTP, VHA09K34RTP, VHA09K50RTP,
VHA09R25RTP, VHA09R34RTP, VHA09R50RTP
1
3 80042925 ASSY TUBE CHECK VALVE
VHA12K
VHA12K25RTP, VHA12K34RTP, VHA12K50RTP,
VHA12R25RTP, VHA12R34RTP, VHA12R50RTP
1
4 61834800 STRAINER .312 COIL ALL 1
5 80044903 ASSY TUBE CHECK VALVE TO
EVAP
VHA09K25RTP, VHA09K34RTP, VHA09K50RTP,
VHA09R25RTP, VHA09R34RTP, VHA09R50RTP
1
5
80042954 ASSY TUBE EVAP TO CHECK VALVE VHA12K25RTP, VHA12K34RTP, VHA12K50RTP, VHA12R25RTP,
VHA12R34RTP, VHA12R50RTP
1
6 80041762 EVAPORATOR COIL, COIL
VES.312X4X16XU9V45A18X13H5
VHA09K25RTP, VHA09K34RTP, VHA09K50RTP,
VHA09R25RTP, VHA09R34RTP, VHA09R50RTP
VHA12K25RTP, VHA12K34RTP, VHA12K50RTP,
VHA12R25RTP, VHA12R34RTP, VHA12R50RTP
1
7 91400402 STUD COMPR MTG ALL 3
8 61028904 GROMMET COMPR LOW DENSITY VHA09K25RTP, VHA09K34RTP, VHA09K50RTP,
VHA09R25RTP, VHA09R34RTP, VHA09R50RTP
3
8 61028904 GROMMET COMP LOW DENSITY VHA12K25RTP, VHA12K34RTP, VHA12K50RTP,
VHA12R25RTP, VHA12R34RTP, VHA12R50RTP
3
9 61718146 KIT COMPR REPLMT 62200507 VHA09K25RTP, VHA09K34RTP, VHA09K50RTP,
VHA09R25RTP, VHA09R34RTP, VHA09R50RTP
1
9 61717190 KIT COMPR REPLACMNT
62200509
VHA12K25RTP, VHA12K34RTP, VHA12K50RTP,
VHA12R25RTP, VHA12R34RTP, VHA12R50RTP
1
10 25063606 COIL SOLENOID 208/230VAC
DUNAN
ALL 1
11 25018305 ASSY VALVE REVERSING VHA09K25RTP, VHA09K34RTP, VHA09K50RTP,
VHA09R25RTP, VHA09R34RTP, VHA09R50RTP
VHA12K25RTP, VHA12K34RTP, VHA12K50RTP,
VHA12R25RTP, VHA12R34RTP, VHA12R50RTP
1
-11.5 80112504 SWITCH HIGH PRESSURE HAZ VHA12K25RTP-B, VHA12K34RTP-B, VHA12K50RTP-B,
VHA12R25RTP-B, VHA12R34RTP-B, VHA12R50RTP-B
1
12 61834800 STRAINER .312 COIL ALL 1
13 60179904 CONDENSATE DRAIN VALVE ALL 1
14 80042938 TUBE SUMP VPAK 09-12K ALL 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
PARTS CATALOG
9K, 12K Refrigeration Assy
Figure 902
