79 PB
PARTS CATALOG
9K, 12K 208/230V
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 60610616 WHEEL BLOWER TA0755 ALL 1
2 80010302 WRAPPER ASSY, INSULATED ALL 1
3 80018403 PLATE SCROLL ALL 1
4 80019002 ASSY INSUL INNERWALL
BLOWER 144mm
ALL 1
5 80002100 BRACKET DISCONNECT ALL 1
6 80007600 NONFUSED DISCONNECT ALL 1
7 20709185 CLAMP, CAPACITOR ALL 1
8 61080702 CAPCTR 25 MF 450V 2.0 ALL 1
9 61613600 SPRING .043 MUSIC WIRE ALL 1
10 61610400 PIN HINGE ALL 1
11 61610300 EXHAUST AIR DOOR ALL 1
-12 03760451 TUBE CAP .049 IDX.099ODX19.5”
RED
VHA09K25RTP, VHA09K34RTP, VHA09K50RTP, 1
-13 03760452 TUBE CAP .049 X .099OD X 35
RED
VHA09K25RTP, VHA09K34RTP, VHA09K50RTP, 1
-14 3760547 TUBE CAP .054 X .106OD X 23.5
WHITE
VHA12K25RTP, VHA12K34RTP, VHA12K50RTP, 1
-15 3760513 TUBE CAP .0X .099 OD X 30 RED VHA12K25RTP, VHA12K34RTP, VHA12K50RTP, 1
-16 61814800 CONNECTOR FRESH AIR S/M ALL 1
-17 61764607 OLP B180-140B-241C 60343539 ALL 1
-18 62600203 SENSOR ID RIA TEMPERATURE
(WHITE
ALL 1
-19 62600205 SENSOR ID COIL TEMPERATURE
(GREEN)
ALL 1
-20 62600206 SENSOR OD COIL TEMPERATURE
(BLUE)
ALL 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
Figure 903
