85 PB
PARTS CATALOG
24K Unit Assembly
Figure 906
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 80102010 ASSY PANEL SIDE BL-24 LF VHA24K25RTP, VHA24K34RTP, VHA24K50RTP, VHA24K75RTP,
VHA24K10RTP, VHA24R25RTP, VHA24R34RTP, VHA24R50RTP,
VHA24R75RTP, VHA24R10RTP
1
2 80103010 ASSY PANEL SIDE BL-24 RT VHA24K25RTP, VHA24K34RTP, VHA24K50RTP, VHA24K75RTP,
VHA24K10RTP, VHA24R25RTP, VHA24R34RTP, VHA24R50RTP,
VHA24R75RTP, VHA24R10RTP
1
3 60542007 FAN PLASTIC 16” LRG; VPAC ALL 1
4 80101011 SHROUD RING WATER TRAP ALL 1
5 61776907 BRACKET MOTOR MOUNT VPAK
LARGE
VHA24RK25RTP, VHA24K34RTP, VHA24K50RTP,
VHA24K75RTP, VHA24K10RTP, VHA24K25RTP,
VHA24K34RTP, VHA24K50RTP, VHA24K75RTP,
VHA24K10RTP
1
6 80102173 MTR 1/4 6P CCW FAN BLCD
NAN-FENG S-1250 VHA24
VHA24K25RTP, VHA24K34RTP, VHA24K50RTP,
VHA24K75RTP, VHA24K10RTP, VHA24K25RTP,
VHA24K34RTP, VHA24K50RTP, VHA24K75RTP,
VHA24K10RTP
1
7 80106601 ASSY REAR PANEL INSUL
PREPNTD
ALL 1
8 80114102 SHROUD, VPAK LARGE FOR RING ALL 1
9
80106708 ASY TOP PANEL INSUL
PREPNTD
VHA24K25RTP, VHA24K34RTP, VHA24K50RTP, VHA24K75RTP,
VHA24K10RTP, VHA24R25RTP, VHA24R34RTP, VHA24R50RTP,
VHA24R75RTP, VHA24R10RTP
1
10 80113900 SUPPORT VPAK 24 ALL 1
11 80106707 BRACKET, TOP FRAME ALL
12 80106706 BRACKET TOP DUCT ALL
-13 61814801 CONNECTOR FRESH AIR LRG ALL 1
-14 61656200 CHANNEL EXHAUST DOOR ALL 1
-15 61656201 SLIDE EXHAUST DOOR ALL 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
