94 PB
PARTS CATALOG
18K 230V Control Box
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 80118402 ASSY C-BOX LARGE 230-265V ALL 1
2 80118601 CONTACTOR 240VAC HCL-
1NU01AAC
VHA18K25RTP, VHA18K34RTP, VHA18K50RTP
1
2 80118602
CONTACTOR 240/277 2 POLES
HCC-2XU04GG
VHA18K75RTP
3 80116907
BRACKET ELECT CNTRL VPAK
LARGE CIRC-BREAKER
ALL
1
4 62601009 KIT E-CNTL SERV COOL HP VHA ALL 1
5 62600118 ASSY E-CNTRL COOL/EH AMP
JMPR
ALL 1
6 61773324 SWITCH CIRCUIT BRKR 20A 230V
CITR220Q2NS
ALL 1
7 62600601 DISPLAY SERVICE VPAC KUHL ALL 1
8 80007600 NONFUSED DISCONNECT ALL 1
9 80116606 CONTROL BOX LID PREPNTD
ALL
1
-10 62600203 SENSOR ID R/A TEMPERATURE
(WHITE)
ALL
1
-11 62600205 SENSOR ID COIL TEMPERATURE
(GREEN)
ALL 1
-12 62600206 SENSOR OD COIL TEMPERATURE
(BLUE)
ALL 1
-ITEMS ARE NON- ILLUSTRATED
*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME
Figure 910
To Next Page
