96 PB

PARTS CATALOG

24K 230V Control Box

ITEM PART

NUMBER

PART DESCRIPTION USED ON MODEL QTY

1 80032809 ASSY CONTROL BOX VPAK 24 XL

230V

ALL

2 61600532 STAND OFF - PCB DIA .125 ALL 4

3 80118601 CONTACTOR 240VAC HCL-

1NU01AAC

ALL 1

4 61080703 CAPCTR 40 MF 450V 2.0” X 3.75” ALL 1

2 80118602 CONTACTOR 240/277 2 POLES

HCC-2XU04GG

ALL 1

5 20709185 CLAMP, CAPACITOR ALL 1

6 80032805 BRACKET E-CTRL VPAK 24 XL ALL 1

7 62601009 KIT E-CNTL SERV COOL HP VHA ALL 1

8 61773324 SWITCH CIRCUIT BRKR 20A 230V

CITR220Q2NS

ALL 1

9 62600601 DISPLAY SERVICE VPAC KUHL ALL 1

10 61643311 RELAY 230V COIL DPDT 30A

208/240VAC

ALL 1

11 80007600 NONFUSED DISCONNECT ALL 1

12 80116606 CONTROL BOX LID PREPNTD

ALL

13 80106975 CONTROL BLOWER MTR PSC

ESM14165

ALL 1

-14 62600203 SENSOR ID R/A TEMPERATURE

(WHITE)

ALL

-15 62600205 SENSOR ID COIL TEMPERATURE

(GREEN)

ALL 1

-16 62600206 SENSOR OD COIL TEMPERATURE

(BLUE)

ALL 1

-ITEMS ARE NON- ILLUSTRATED

*ITEMS ARE NON-STOCKED, WILL NORMALLY REQUIRE 2-3 WEEKS LEAD TIME

Figure 911
