98 PB
ITEM PART
NUMBER
PART DESCRIPTION USED ON MODEL QTY
1 80118402 ASSY C-BOX LARGE 230-265V ALL 1
2 80118601 CONTACTOR 240VAC HCL-
1NU01AAC
VHA18R35RTP, VHA18R34RTP, VHA18R50RTP 1
2 80118602 CONTACTOR 240/277 2 POLES
HCC-2XU04GG
VHA18R75RTP 1
3 61643311 RELAY 230V COIL DPDT 30A
208/240VAC
ALL 1
4 80116907 BRACKET ELECT CNTRL VPAK
LARGE CIRC-BREAKER
ALL 1
5 62601009 KIT E-CNTL SERV COOL HP VHA ALL 1
6 62600118 ASSY E-CNTRL COOL/EH AMP
JMPR
ALL 1
7 61773324 SWITCH CIRCUIT BRKR 20A 230V
CITR220Q2NS
ALL 1
8 62600601 DISPLAY SERVICE VPAC KUHL ALL 1
9 61670803 TRANSFORMER IN 265V OUT
235V
ALL 1
10 80007600 NONFUSED DISCONNECT ALL 1
11 61776111 FUSE BLOCK 3 POLES 30 AMP ALL 1
12 61773317 FUSE 600V 20A CC TD ALL 1
13 61773319 FUSE 600V 15A CC TD ALL 2
14 80117001 LOCK MECHANISM BALL BEARING ALL 1
15 90603405 SCREW 4F-40X3/8 ROUND PAN
PHILL ZIN
ALL 1
16 90605602 SCREW PHILLIPS #10-32 X .250 ALL 1
17 61610400 PIN HINGE ALL 1
18 80015707 COVER CONTROL BOX DOOR ALL 1
19 80086100 KNOB KNURLED ALL 1
20 90605301 SCREW #8 SG X 3/8 HWH B PT ALL 1
21 91201202 RIVET ID .093 PLASTIC ALL 1
22 80116603 CONTROL BOX LID PREPNTD
ALL
1
-23 62600203 SENSOR ID R/A TEMPERATURE
(WHITE)
ALL
1
-24 62600205 SENSOR ID COIL TEMPERATURE
(GREEN)
ALL 1
-25 62600206 SENSOR OD COIL TEMPERATURE
(BLUE)
ALL 1
PARTS CATALOG
18K 265V Control Box
Figure 912
