16 PB
SPECIFICATIONS
Electrical Data
6
Electrical Data
MCA = Minimum Circuit Ampacity
MOP / MOCP - Maximum Overcurrent Protection / Breaker Size
Minimum Circuit Amps (MCA) and MOCP values in the above table are calculated in accordance with The NEC.Article 440
Electrical Requirements
Wire Size Use ONLY wire size recommended for
single outlet branch circuit.
Fuse/Circuit
Breaker
Use ONLY type and size fuse or HACR cir-
cuit breaker indicated on unit’s rating guide.
Proper over current protection to the units is
the responsibility of the owner.
Grounding Unit MUST be grounded from branch circuit
to unit, or through separate ground wire
provided on permanently connected units.
Ensure that branch circuit or general pur-
pose outlet is grounded.
Wire Sizing Use recommended wire size given in tables
and install a single branch circuit. All wiring
must comply with local and national codes.
NOTE: Use copper conductors only.
Electrical Rating Table
NOTE: Use copper conductors ONLY. Wire sizes are per NEC.
Recommended Branch Circuit Sizes*
Nameplate Maximum Circuit Breaker Size AWG Wiring Size**
15A 14
20A 12
AWG - American Wire Gauge
* Single circuit from main box.
** Based on 100’ or less of copper, single insulated conductor at 60˚ C
NOTE: All eld wiring must comply with NEC and local codes. It is the installer’s responsibility to ensure that the electrical codes are
met.
VRP Model Voltage
Electric
Heater
Watts
Electric
Heating
Btu
ID Blower
Amps
OD Blower
Amps
Total
Electric
Heating
Amps
MCA MOP / MOCP
VRP07K
230 0 0 0.6 0.5 0
8.1 15
208 0 0 0.7 0.5 0
230 2500 8530 0.6 0.5 11.5
14.4 15
208 2045 6980 0.7 0.5 10.6
230 5000 11600 0.6 0.5 15.4
19.3 20
208 4100 9490 0.7 0.5 14.1
VRP07R 265
0 0 0.5 0.5 0 7.9 15
2500 8530 0.5 0.5 9.9 12.5 15
3400 11600 0.5 0.5 13.3 16.7 20
Figure 205
