J. STARTUP AND OPERATION
J.3 Control Panel Operation
MENU RETURN
MENU
RETURN
The TM Menu continued
Auto mode selected. See Figure J.3.16.
Set the cool setpoint for your rst timer period using the arrow buttons.
The cooling mode timer only sets the cool setpoint. See Figure J.3.17.
Next, set the heat setpoint for your rst timer period. The heating mode
timer only sets the heat setpoint. See Figure J.3.18.
Figure
J.3.16
Figure
J.3.17
MENU
RETURN
Figure
J.3.18
Figure
J.3.19
Note: The auto mode timer sets both the cool and heat setpoint.
Set the time to start the rst timer period. See Figure J.3.19.
MENU
RETURN
