P. Appendixes
P.1 Accessories and Options
M. TROUBLESHOOTING
M.2 Diagnostic Codes (Cont.)
12 Discharge Air greater than 185°F Shutdown electric heater. Wait for the discharge air temperature to be less than 100°F.
Resume operation.
13 High Pressure Switch Open Turn compressor off. Wait until pressure switch is no longer open. Resume operation
after lockout time.
14 Discharge Air Temperature Sensor is
Open or Shorted
Override Sensor. Set temp to 75°F. Continue to monitor. Set error code 14 ON.
16 Temperature Beyond Operating Limits Ambient temp is less than 0°F or greater than 130°F. Turn off compressor,
electric heat, and fan. When cleared resume operation.
22 Outdoor Coil Temperature less than 30°F
for 2 consecutive Minutes
Only applicable to units with heat pump and electric heat. Turn off heat pump
operation. Use electric heat to satisfy all heating demands. Cleared when
outdoor coil temp is greater than 45°F.
23 Frost Protection. Only applicable to heat pump only units. Active when Heat Pump run time
exceeds 60 minutes with the outdoor coil temp less than 26°F. Runs active
defrost for up to 6 minutes.
DK / Drain Kit
Installed at the back of the unit and allows for
attachment to condensate disposal system, if
necessary or desired.
IDK / Internal Drain Kit
New construction applications where a condensate
drain system has been built into the wall interior.
BAK / Baffle Adapter Kit
Necessary when installing in a sleeve deeper than 16¾”
deep, such as Fedders B sleeve (19¾” deep).
WSE Wall Sleeve
Ships with standard grille and standard galvanized
steel inner panel and painted steel outer panel.
A
WSE SLEEVE
B 61603200 INDOOR WEATHER PANEL (METAL)
C 61603304 OUTDOOR WEATHER PANEL (PAINTED METAL)
D 61603012 ASSY GRILLE WSE SLEEVE
E 61578101 GASKET (ATTACHED TO SLEEVE)
Outer weather panel
Architectural Grille- AG
Premium extruded aluminum grille. Optional
accessory.
