Product Information
and Technical Guide
2004 Room Air Conditioners
5995413183
July 2004
ATTENTION SERVICERS!
To get a helping hand, visit the
Frigidaire Web Site at:
User name: service
Password: tips
http://www.frigidaire.com
Safe Servicing Practices 3
Model Specifications 4-7
Compressor Overloads 8
Restrictor Tube Data 8
Receptacle Codes 9
Product Dimensions 10
Thermostat Dia
g
rams 11-12
Fan/Blower Dia
g
rams 13-14
Wiring Diagrams 15-17
Troubleshooting 18-20

Table of Contents

Questions and Answers

  • R
    Roger PetersonAug 20, 2025
    Why won't the fan motor run on my Frigidaire FAS156N1A Air Conditioner?
    • J
      jeffrey51Aug 20, 2025
      If the fan motor of your Frigidaire Air Conditioner will not run, here are several things to check: - First, verify the power supply. - Inspect the power supply cord. - Check the selector switch and the energy-saving switch (if your unit has one). - If applicable, consider replacing the electronic control. - Inspect and secure any loose wire connections. - If you are qualified, discharge the capacitor before testing it. - As a last resort, the fan motor might be defective and require replacement.
  • J
    Jennifer JordanAug 22, 2025
    What to do if Frigidaire FAS156N1A compressor won't run but fan does?
    • M
      mark16Aug 22, 2025
      If the compressor of your Frigidaire Air Conditioner isn't running but the fan motor is, you should: - Check the voltage. - Inspect the wiring. - Check the selector switch and inspect the temperature control. - Discharge the capacitor before testing it.
  • M
    Maurice MorganAug 25, 2025
    Why is my Frigidaire Air Conditioner producing excessive water?
    • M
      Ms. Rebecca MolinaAug 25, 2025
      If you notice excessive water or condensation from your Frigidaire Air Conditioner, it might be operating under extremely high humidity conditions. Try to reduce the humidity in the room.
  • Z
    Zachary PalmerAug 26, 2025
    Why is my Frigidaire FAS156N1A Air Conditioner evaporator icing?
    • C
      christopher71Aug 26, 2025
      If the evaporator is icing in your Frigidaire Air Conditioner, it might be due to low voltage reducing the fan speed, which results in inadequate airflow over the evaporator. To resolve this, repair or replace any malfunctioning line voltage component before testing or replacing the electronic control.
  • M
    Michael ReedAug 28, 2025
    Why does my Frigidaire Air Conditioner dim the lights when running?
    • L
      Lori PerezAug 28, 2025
      If you notice lights dimming when your Frigidaire Air Conditioner is running, it's likely due to a voltage issue. Repair or replace any malfunctioning line voltage component before testing or replacing the electronic control.
  • S
    sabrinacuevasAug 30, 2025
    Why is the evaporator coil partially frosted on my Frigidaire FAS156N1A?
    • A
      Amber SmithAug 30, 2025
      If the evaporator coil in your Frigidaire Air Conditioner is partially frosted, the system may be low on refrigerant. Add refrigerant to resolve this issue.
  • R
    Regina McintyreSep 1, 2025
    Why is the wattage continuously high on my Frigidaire FAS156N1A?
    • C
      Carl DeleonSep 1, 2025
      If the wattage of your Frigidaire Air Conditioner is continuously high, it indicates a refrigerant overcharge. Reduce the amount of refrigerant to fix this.
  • D
    Donna GrantSep 3, 2025
    Why does the fan motor on my Frigidaire FAS156N1A run intermittently?
    • M
      moranwilliamSep 3, 2025
      If the fan motor on your Frigidaire Air Conditioner runs intermittently, it could be cycling on the motor protector. Check the motor protector to resolve this.
  • W
    wilkersonadrianSep 4, 2025
    What causes blown fuses in my Frigidaire FAS156N1A Air Conditioner?
    • S
      Scott BradleySep 5, 2025
      Blown fuses in your Frigidaire Air Conditioner may be caused by voltage issues. Repair or replace any malfunctioning line voltage component before testing or replacing the electronic control.
  • E
    Eric OneillSep 7, 2025
    Why is there premature failure of compressor or fan motor in my Frigidaire FAS156N1A Air Conditioner?
    • M
      Mark MitchellSep 7, 2025
      Premature failure of the compressor or fan motor in your Frigidaire Air Conditioner could be due to voltage issues. Repair or replace any malfunctioning line voltage component before testing or replacing the electronic control.

Summary

Safe Servicing Practices

Frigidaire Model Specifications

Control Thermostat Location Diagrams

Various Control Types Thermostat Location

Thermostat location diagrams for Slider Casement, Compact Electronic, and Rotary controls.

Fan and Blower Location Diagrams

Compact Fan and Blower Location

18.5 No Side Louvers Fan and Blower Location

Slider Casement Fan and Blower Location

Wiring Diagram A232012

Wiring Diagram 309201102;02

Wiring Diagram 309201101;02

Wiring Diagram 309902101;01

Room Air Conditioners Troubleshooting

Air Conditioner Voltage Limits

Limits for operating voltage for air conditioners.

High Voltage Issues

Electronic Control Troubleshooting

Frigidaire FAS156N1A Specifications

General IconGeneral
Cooling Capacity15, 000 BTU
Energy Efficiency Ratio (EER)9.8
Power Supply115V/60Hz
Weight90 lbs
TypeWindow Air Conditioner
RefrigerantR-410A
Noise Level56 dB(A)
Noise Level (High)56 dB(A)
