Frigidaire FAS156N1A - Compressor Overloads; Compressor Overload Data; Restrictor Tube Data

8
Minimum Maximum
A112114 Red 35.00 0.112 0.059 10 0.294 0.318
A112115 Red 40.00 0.112 0.059 10 0.274 0.296
A112129 Purple 45.00 0.097 0.046 25 0.261 0.283
A112138 Black 33.00 0.099 0.049 20 0.304 0.330
A112153 Blue 37.50 0.125 0.064 10 0.227 0.247
A112156 Black 38.19 0.099 0.049 20 0.352 0.382
A112157 Black 19.69 0.099 0.049 20 0.181 0.197
A112158 Black 23.62 0.099 0.049 20 0.218 0.236
A112159 Black 29.13 0.099 0.049 20 0.268 0.291
A112124 White 45.00 0.106 0.054 20 0.346 0.374
A112137 Purple 51.18 0.097 0.046 25 0.248 0.268
A112104 Black 45.00 0.099 0.049 20 0.258 0.280
A112116 White 40.00 0.106 0.054 20 0.366 0.396
A112129 Purple 45.00 0.097 0.046 25 0.261 0.283
A112145 Black 37.00 0.099 0.049 20 0.288 0.312
A112119 Black 35.00 0.099 0.049 20 0.296 0.320
I.D PSIG
CFM Dry Air
Restrictor Tube Data
Style#
Internal Diameter
Color Code
Length O.D.
Test Amp Opening Time-Sec
309260303 2R11S3R126A6A MRA98705
A363785 QK134CCA MRA12061-12056
150 61 50.5
6-16
A363785 QK141CCA MRA12061-12056
150 61 50.5
6-16
A363776 QK164CCA MRA12053-12057
150 61±9 C° 41.5
6-16
A363784 QK191CAB MRA4720-12057
150 69 50.3
2-12
A363786 QK141KBE MRA12054-12056
155±7 C° 69 14.5
6-16
A363788 QK164KBC MRA12124-12056
155 69 19.0
6-16
A363771 QJ258KAB MRA12044-12057
160 61 29.0
6-16
A363789 QJ250KBA MRA12107-12057
150 69 27.3
6-16
*Terminal to overload must withstand 10 pounds pull test.
Compressor Overload Data
Closing Temp
C°± 11 C°
Short Time Trip at 25 C°
Part# Used With Compressor Supplier Part#
Opening Temp
C°± 5 C°
