FRIGIDAIRE MODEL SPECIFICATIONS
Model FAK103N1V FAK123N1V
Chassis Type
Slider
Casement
Slider
Casement
Capacity Features
BTU - Cooling
BTU - Heating
Moisture Removal
EER
10000
-
2.8
9.5
12000
-
3.6
9.5
Electrical Information
Voltage
Amps - Cooling
Amps - Heating
Watts - Cooling
Watts - Heating
Fuse/Breaker (Amps)
Receptacle Code
Wiring Diagram
Page #
115
9.6
-
1050
-
15
A
A232012
15
115
11.5
-
1260
-
15
A
A232012
15
Air Flow System
Capacitor-µ farads
Fan Motor Mfg.
Fan Motor Number
RPM/CMP (EVAP)
High
Medium
Low
Heat Only
15/370
Heshan
309646001
1400/305
1230/260
1050/210
-
15/370
Heshan
309646001
1400/305
1230/260
1050/210
-
Refrigeration System
Compressor Mfg.
Compressor Number
Compressor Type
Overload Protector
Capacitor-µ farads
Refrigerant Charge
Restrictor Tube
Thermostat Type
LG
QK134CCA
Rotary
A363785
50/370
20.46
A112137
Bulb
LG
QK164CCA
Rotary
A363776
50/370
23.28
A112104
Bulb
Installation Instructions
Kit Type
Part Number
V
309625802
V
309625802
Control Thermostat
Location Diagram
Page 11 Page 11
Condenser Fan and
Evaporator Blower
Location Diagram
Page 13 Page 13
