15
BEFORE SETTING SURFACE CONTROLS
Install Burner Grates
To install burner grates, place the grates fl at-side
down and align them into the cooktop recess..
IMPORTANT
• Make sure the burner grates are proper-
ly placed on the cooktop before using the
surface burners (Figure 4). The grates are
designed to rest inside the recess on the
cooktop.
• Grates should rest fl ush against each other
and against the sides of the recess.
• Do not line the area underneath the grates or
any part of the cooktop with aluminum foil or
with any other lining.
Figure 4: Grate installation
Home Canning
Be sure to read and observe all the following points
when home canning with your appliance. Check
with the USDA (United States Department of Agri-
culture) Web site and be sure to read all the infor-
mation they have available as well as follow their
recommendations for home canning procedures.
• Use only a completely fl at bottom canner with
no ridges that radiate from the bottom cen-
ter when home canning. Heat is spread more
evenly when the bottom surface is fl at. Use a
straight-edge to check canner bottom.
• Make sure the diameter of the canner does
not exceed 1 inch beyond the surface element
markings or burner.
• It is recommended to use smaller diameter can-
ners on electric coil and ceramic glass cooktops
and to center canners on the burner grates.
• Start with hot tap water to bring water to boil
more quickly.
• Use the highest heat setting when fi rst bringing
the water to a boil. Once boiling is achieved,
reduce heat to lowest possible setting to main-
tain that boil.
• Use tested recipes and follow instructions care-
fully. Check with your local Cooperative Agri-
cultural Extension Service or a manufacturer of
glass jars for the latest canning information.
• It is best to can small amounts and light loads.
Do not leave water bath or pressure canners on
high heat for an extended amount of time.
