FES367CES/B/T Pub li ca tion No.
5995315347
# = Func tional Part 9 11/98
* = Non-Illustrated Part
DOOR
POS. NO PART NO DE SCRIP TION
1 318043100 A B C D E F Bracket-trim/ Sup port montage
3 318049206 A B Trim-oven door white/ Moulure lat. porte
3 318049205 C D Trim-oven door black/ Moulure lat. Porte
3 318049207 E F Trim-oven door al mond/ Moul. Lat. porte
3A 318028900 A B C D E F Trim-oven door/ Moulure sup. pan. verre
3B 318049020 A B Trim-oven door white/ Moulure sup. porte
3B 318049019 C D Trim-oven door black/ Moulure sup. Porte
3B 318049021 E F Trim-oven door al mond/ Moul. Sup. porte
4 318041102 A B Glass-oven door white / Pan. Ver. déco.
4 318041105 C D Glass-oven door black / Pan. Verre déco
4 318041103 E F Glass-oven door al mond/ Pan. Verre déco
6 318056802 A B C D E F Shield-insulation/ Déflecteur porte
7 318106001 A B C D E F In su la tion-door/ Isolant
9 318048802 A B C D E F Liner-oven door/ Ass. Contre-porte
10 5303324305 A B C D E F Screw 10-24 X 5/8/ Vis
12 318053103 A B C D E F Seal-oven door/ Joint contre-porte
16 318041603 A B C D E F Glass-oven door/ Panneau verre
17 318042102 A B C D E F Spacer-glass/ Encadrement intérieur
18 318053001 A B C D E F Seal-window/ Joint
20 318014301 A B Spacer-handle white/ Entretroise poignée
20 318014300 C D Spacer-handle black/ Entretoise poignée
20 318014302 E F Spacer-handle al mond/ Entretoise poignée
23 5303311215 A B C D E F Hinge-oven door/ Ass. charnière
23* 3201899 A B C D E F Washer/ Rondelle plate
29 5303310535 A B C D E F Bumper base/ Entretoise caou tchouc
31 5303310536 A B C D E F Latch-door/ Gâche porte
39 316091119 A B Han dle-door white/ Poignée porte blanche
39 316091121 C D Han dle-door black/ Poignée porte noire
39 316091120 E F Han dle-door al mond/ Poignée porte aman.
42 5303311194 A B Trim-oven door white/ Moulure inf. porte
42 5303311200 C D Trim-oven door black/ Moulure inf. Porte
42 5303311198 E F Trim-oven door al mond/ Mou. Inf. porte
54 5303317175 A B Screw 8-18 X ½ white/ Vis
54 5303308456 C D Screw, 8-18 X ½ black/ Vis
54 5303300265 E F Screw, 8-18 X ½/ Vis
* 08016432 A B C D E F Screw, 8-18 X 3/8/ Vis
* 5303211311 A B C D E F Screw, #8 X ½/ Vis
* 5303307980 A B C D E F Screw, 8-32 X 7/16/ Vis
A= FES367CE (FES367CESC)
B= FES367CE (FES367CESE)
C= FES367CE (FES367CEBC)
D= FES367CE (FES367CEBE)
E= FES367CE (FES367CETC)
F= FES367CE (FES367CETE)
