Frigidaire FFGH3054UB User Manual

18
Oven Vent Location
The oven is vented as shown below. When the oven is on,
warm air is released through the vent. This venting is
necessary for proper air circulation in the oven and good
baking results. Do not block oven vent. Never close off the
openings with aluminium foil or any other material. Steam or
moisture may appear near the oven vent. This is normal.
Types of oven racks
• Flat oven racks may be used for all cooking needs and
may be placed in most oven rack positions.
Removing, replacing, and arranging flat oven
racks
Always arrange the oven racks when the oven is cool.
To remove - Pull the oven rack straight forward until it
reaches the stop position. Lift up front of oven rack slightly
and slide out.
To replace - Place the oven rack on the rack guides on
both sides of oven walls. Tilt the front of oven rack upward
slightly and slide the oven rack back into place. Be sure
oven racks are level before using.
Figure 10: Oven vent
Protective Liners — Do not use aluminum foil or any
other material or liners to line the oven bottom, walls,
racks or any other part of the range. Doing so will alter the
heat distribution, produce poor baking results, and
possibly cause permanent damage to the oven interior.
Improper installation of these liners may result in risk of
electric shock or fire. During self clean, temperatures in
the oven will be hot enough to melt foil.
If the cooktop is used during a self-clean cycle, the oven
may turn off. The oven control display will show “SCC"
for 5 seconds. The oven door will remain locked until the
oven has cooled down below cleaning temperature. If the
oven is below cleaning temperature, the user can start
another clean cycle immediately. If the oven is in cleaning
temperature range, another self-clean cycle can be set
once the door unlocks (up to 4 hours).
WARNING
IMPORTANT
• Always use pot holders or oven mitts when using the
oven. When cooking, the oven interior, oven exterior,
oven racks, and cooktop will become very hot which
can cause burns.
• Remove all oven racks before starting a self clean
cycle. If oven racks are left inside the oven during a
cleaning cycle, the slide ability of the oven racks may
be damaged and all of the oven racks will lose their
shiny finish.
• To prevent possible damage to the oven, do not
attempt to close the oven door until all the oven racks
are fully positioned back inside the oven cavity.
Figure 11: Oven rack types
CAUTION
at
oven rack
BEFORE SETTING OVEN CONTROLS

Frigidaire FFGH3054UB Specifications

General

Style	slide-in
Color	black
Main Capacity	5 cu. ft.
Temperature Probe	no
Convection	no
Grill	no
Number of Burners	5
Number of Racks	2
Control Type	touch sensor; knobs
Interior Light	yes
Wi-Fi	no
Fuel	natural gas; gas
Voltage	120 volts
Current	5

Weight and Dimensions

Depth	26 6/8" (without handle)
Height	36 5/8 inch
Width	29 7/8 inch
