Frigidaire FFRE0833S1 User Manual

4
Installation
FIG. 13
FIG. 14
FOAM SEAL
Cut foam window seal and insert it into the space between the upper and lower sashes (FIG. 14).
NOTE: It is difficult to lock the windows with the sash lock for Vinyl-Clad windows, so you can use lock by
(FIG. 13).
window itself.
FIG. 10
FIG. 11 FIG. 12
9
Measure the inner width
of the side curtain
1
2
3
4
5
6
7
8
9
10
1
112
13
14
15
1
2345
6
or
Measure the width of the inner side curtain with the provided ruler, as shown (FIG. 10). Mark a line on the
patterned side of the provided insulation panel according to the measured width, then cut out the insulation
panel along the line, as shown (FIG.11). Place the patterned side of the insulation panel to face inside your
room, then slide the insulation panel into the frame until the panel goes into the side curtain frame completely.
If the insulation panel does not slide in the frame smoothly, trim the insulation panel then try again, until the
insulation panel fits the frame, as shown (FIG.12). Repeat these instructions for the other side.

Frigidaire FFRE0833S1 Specifications

General

Type	Window air conditioner
Timer type	Digital
Certification	UL/CUL
Number of speeds	3
Remotely operated	Yes
Refrigerating medium	R410A
Timer duration (maximum)	24 h
Air conditioner functions	Cooling, Dehumidifying
Cooling capacity in watts	- W
Sustainability certificates	ENERGY STAR
Suitable for room area up to	32.5 m²
Cooling energy efficiency (EER, W/W)	-
Product color	White
AC input voltage	115 V
AC input frequency	60 Hz
Power consumption (cooling)	665 W

Weight and Dimensions

Depth	444.5 mm
Width	470 mm
Height	341.3 mm
Weight	23586 g
Package depth	495.3 mm
Package width	562 mm
Package height	374.65 mm
Package weight	27215 g
Window opening width (max)	914.4 mm
Window opening width (min)	584.2 mm
Window opening height (min)	355.6 mm
