4.2 Knowing your Danfoss ERC-112 Controller*
For instructions of the functionality of Danfoss ERC-112 Controller and its related optional features,
please visit the following website link: http://www.frigoglass.com/manuals/.
5. Door blocking system
In using the door blocking system, please follow the steps below
5.1 Application with hinged door ICMs
Step 1: Open the door to an angle greater than 110 degrees
Step 2: Rotate the door blocker towards the cabin (as shown in the picture)
Step 3: Door blocker stops on the screw located over the grid (as shown in the picture)
Step 4: Open the door to release the door blocker from the stopping point and rotate to the initial
position
5.2 Application with sliding door ICMs
Step 1: Open the left door (same procedure also for right door)
Step 2: Lift up and rotate the door blocker towards the cabin (as shown in the picture)
Step 3: Place door blocker vertical to door guides (as shown in the picture). Door blocker will be
blocked at door guides walls and prevent the door to close.
Step 4: Release the door blocker from the stopping point and rotate to the initial position
6. Locking system
6.1 Instructions for using the padlock provision
Step 1: Open the door
Step 2: Rotate the locking system blade placed on the grid (as shown in the picture)
Step 3: Rotate the locking system blade placed on the door (as shown in the picture)
Step 4: Close the door and place the pad lock through the blade holes to secure cooler
*
optional feature, depending on the model
