ENGLISH - 22
“OMEGA” CARD PROGRAMMING TABLE (*)
STEP DESCRIPTION MIN MAX T1 T2 T3S STEP
P1
Consistency hysteresis (%
set of consistency)
1 50 12 15 12
1% of set of consistency
P2
Set OK
50 150 110 100 110
1 consistency value
number
P3
Compressor ON in
delivery
0 1 1 0 0
0= disabled
1= enabled
P4
Amperage selection TA
2A 32A 12A 8A 6A
2A (AMP. Agitator in
batch freezing)
P5
Amperage selection TA in
granita function
2A 32A 6A 4A 4A
2A (AMP. Agitator in
granita)
P6
Compressing time ON in
delivery
0 1 0 0 0
0= 2”, 1=12”
(if P3 enabled)
P7
Sampling interval TA
0 4 0 0 0
0=4”, 1=8”, 2=12”, 3=
16”, 4= 20”.
P8
Voltage selection (Hz)
0 2 0 0 0
0= 400/50, 1= 220/60,
2=220/50
P9
Alarm for lack of growth
0 1 0 0 0
0= enabled (time-out 16
min.)
1=disabled (time-out 35
min.)
P10
Alarm compressor reset in
automatic cycle if
consistency is less than
“SET OK”
0 1 0 0 0
0= disabled
1= enabled
(*)The parameters can change according to the software versions or to customising
processes. It is always possible to refer to the test card supplied with the machine.
SPECIAL FUNCTIONS
Beep silencer
When the beep is released, press the function key, which is then active, to silence the
beep until it is possibly released again according to the situation.
SKIP function
For time steps, normally indicated by the blinking on the display, press the function key,
which is then active, for al least 5 seconds to zero the time of the current step.
Set/time visualization
Press the active key to visualise the time of the current step. The key must be released
within five seconds, otherwise the SKIP function is activated.
Energy saving mode
One minute after a key has been pressed, the display brightness is reduced to decrease
the card power absorption. The maximum brightness is restored as soon as that key is
pressed again.
