2 INSTALLATION
M-7.3-16 Rev. 05 09/03/15 BLOOD BANK REFRIGERATORS AND PLASMA FREEZER 10
Use and maintenance manual
2.1 TRANSPORTATION AND HANDLING
The appliance must be transported and handled exclusively in upright position, in
observance of the instructions printed on the packing.
This precaution is necessary to avoid contamination of the refrigerant circuit with compressor lube
oil with resulting valve and heat exchanger coil failure and problems starting the electric motor.
The manufacturer cannot be considered responsible for any problems due to transport executed in
conditions other than those specified herewith.
The appliance is secured to a wooden base by means of a screw and wrapped in a cartoon box
and if requested by the client, cartoon box and wooden crate.
The appliance must be handled using a folk lift truck or a pallet truck with suitable forks (fork
length at least equal to 2/3 length of unit). The dimensions and weight of the packed appliance are
shown in technical tables (see tables at the beginning of manual).
2.2 POSITIONING
Incorrect positioning can cause damage to the appliance and generate hazardous conditions for
personnel. The installer must therefore observe the following general regulations:
Make sure you maintain a minimum of 10 cm. from the walls and the ceiling
The room must be well ventilated
Keep well away from sources of heat
Avoid direct sunlight
Remove packing material
Remove accessories from inside the unit
Wood basement removal: by means of a hammer until the feet-block hinder ledge, tilt the
cabinet to one side and loosen the two thread-forming screws by means of a socket wrench,
drag the cabinet from the back side holding the basement still until the four feet have gone out
from the containing holes, slightly tilt the cabinet backward and take the basement away
pulling it from the front side.
Use gloves when handling wooden packing materials and the wooden base to protect the
hands from splinters.
Position the appliance with the help of a spirit level. Adjust the levelling feed on the metal base
of the unit if necessary.
Remove the protective PVC film from the external surfaces of the unit
2.3 WIRING AND ELECTICAL HOOK-UP
The electrical plant and electrical hook-up operations must be performed by a qualified electrician.
For safety reasons adhere to the following indications:
Check that the electrical plant is suitably sized for the absorbed power of the unit
If the electrical socket and the plug on the appliance power cord are incompatible, charge the
plug with a suitable component, ensuring the replacement part is of the approved type
Insert the cable into the jack (Fig. 1)
Do not use reductions or multi-way adapters (Fig. 2)
- It is important to connect the appliance correctly to an efficient earth system executed in
compliance with the relevant legislation.
- The appliance must be positioned so that plug can be easily reached (Fig. 2)
