10.4 Sealing the strap
The sealing valve lever A48.1233 is pressed down
until the seal is notched and the upper strap
sheared; the tensioning process is interrupted
automatically.
10.5 Releasing the tool
The tool can be released from the strapping without
any further action after completing the strapping
cycle. By lifting the air motor the strap end is
removed from the tool.
10.6 Tension regulation
The tension is regulated by the continuous
adjustment of the throttle screw L2.1412. The air
supply is reduced by turning the screw clockwise.
The throttle screw is located at the rear end of the air
motor.
