Fromm P324 - Page 23

[ ] = Group * = Wearing parts
23
43062301.een.fm
14 SPARE PARTS LIST 43.0623.01
43.0623.01 P324/12.7/0.40-0.64 P324.0001.01 23.04.07
Item-No. in group Pcs. Description Dimension Field
N1.1305 P32.0147 2 SCREW M4 X 7.8 D8
N1.1553 P32.1250 1 HEXAGON SCREW M4 X 8 C11
N1.1904 5 SCREW M5 X 20 D6+
N1.1909 2 FLAT HEAD SCREW M3 X 5 D3
N1.1922 P32.0147 1 SCREW M3 X 10 B17
N1.1927 P32.0147 1 FLAT HEAD SCREW M4 X 60 A19
N1.1929 1 SCREW M5 X 50 D12
N1.1934 P32.0147 4 FLAT HEAD SCREW M4 X 50 A19
N1.1952 P32.0147 4 FLAT HEAD SCREW M4 X 20 A7
N1.2112 P32.0118 3 COUNTERSUNK SCREW M4 X 10 B15
N1.2216 1 COUNTERSUNK SCREW M3 X 8 D4
N1.2216 P32.0152 3 COUNTERSUNK SCREW M3 X 8 B23
N1.2223 1 COUNTERSUNK SCREW M3 X 6 D5
N1.3150 P32.1414 1 SOCKET SET SCREW M3 X 8 C24
N1.5120 P32.1414 1 HEXAGON NUT M3 C24
N1.6331 P32.0147 4 SPACER WASHER 6 X 12 X 0.5 B14+
N1.6344 P32.0147 1 SPACER PIECE 6.3 X 15 X 5 D14
N1.6503 6 SAFETY WASHER M5 C6+
N1.6504 P32.0147 11 SAFETY WASHER M4 A7+
N1.6504 P32.1250 1 SAFETY WASHER M4 C11
N1.6505 2 SAFETY WASHER M3 D3
N1.6505 P32.0147 1 SAFETY WASHER M3 C17
N1.7206 P32.2043 1 PT-SCREW 2.2 X 10 C20
N1.7211 P32.0148 7 PT-SCREW 3 X 20 A20
N2.1118 P32.0148 1 SECURITY RING 6 C24
N2.1121 1 SECURITY RING 5 C11
N2.1121 P32.0147 4 SECURITY RING 5 D9+
N2.1606 P32.0148 1 SPRING RING SW6 A20
N2.1610 P32.0147 1 SPRING RING SB44 B15
N2.1805 P32.0147 1 TENSIONING RING 6 C14
N2.2110 P32.0153 1 PARALLEL PIN 4 m6 X 10 B2
N2.2119 P32.0140 1 PARALLEL PIN 4 m6 X 18 C17
N2.2122 P32.0140 2 PARALLEL PIN 3 h6 X 14 C17
N2.2145 P32.0118 3 PARALLEL PIN 4 h6 X 18 B16
N2.2187 P32.0110 2 PARALLEL PIN 3 m6 X 6 C5
N2.2187 P32.0153 1 PARALLEL PIN 3 m6 X 6 A3
N2.2188 P32.0153 3 PARALLEL PIN 5 h6 X 34 B3
N2.2189 P32.0136 4 PARALLEL PIN 3 m6 X 5 D3
N2.2190 P32.0147 1 PARALLEL PIN 6 h6 X 18 B17
N2.2193 1 PARALLEL PIN 3 m6 X 32 C10
N2.2443 P32.0139 1 DOWEL PIN 4 X 15 A8
N2.3342 P32.0147 1 FEATHER KEY 2 X 2 X 10 C1
N2.4902 2 HAMMER HEAD BOLT 1.85 X 4.76 C6
N2.4902 P32.0147 2 HAMMER HEAD BOLT 1.85 X 4.76 A7
N2.5153 P32.0148 1 PRESSURE SPRING 0.4 X 4.1 X 16/10.5 A21
N2.5157 P32.0147 2 PRESSURE SPRING 0.6 X 4.8 X 20/15.5 C8
N2.5178 2 PRESSURE SPRING 0.32 X 2.82 X 20.5/
20.5
C10
N2.5237 1 PRESSURE SPRING 0.8 X 4.8 X 25/18.5 C10
N2.5294 P32.0139 1 PRESSURE SPRING 2.5 X 15 X 46.5/9.5 B8
N2.5295 P32.0147 1 PRESSURE SPRING 1.5 X 21 X 27/5.5 B8
