Fromm P324 - Page 24

[ ] = Group * = Wearing parts
24
43062301.een.fm
N2.5296 P32.0147 1 PRESSURE SPRING 0.5 X 4 X 24/16.5 C9
N2.5822 P32.0147 1 TORSION SPRING 1.25 X 12/3.75 D14
N2.5823 1 TORSION SPRING 2.8 X 17/4 D4
N31.1118 P32.0148 2 BALL BEARING 10 X 19 X 5 C21
N31.1120 P32.0148 1 BALL BEARING 4 X 11 X 4 B21
N3.1134 P32.0147 1 BALL BEARING 7 X 22 X 7 A16
N3.1134 P32.1021 1 BALL BEARING 7 X 22 X 7 A18
N3.1137 P32.0148 2 BALL BEARING 15 X 24 X 5 B22
N3.1137 P32.0150 1 BALL BEARING 15 X 24 X 5 B23
N3.1157 P32.0118 1 BALL BEARING 30 X 42 X 7 C16
N3.1159 P32.0147 1 BALL BEARING 6 X 19 X 6 B18
N3.1160 P32.0154 1 BALL BEARING 40 X 52 X 7 A14
N3.1172 2 BALL BEARING 30 X 42 X 7 B3+
N3.1178 P32.0120 1 BALL BEARING 35 X 44 X 5 A14
N3.1702 P32.0147 6 BALL 4 MM D9
N3.2105 P32.0118 3 NEEDLE CAGE K 4 X 7 X 7 TN B15
N3.2106 3 NEEDLE CAGE K 5 X 8 X 10 TN B3
N3.2346 P32.0110 1 NEEDLE CASE 8 X 12 X 8 C5
N3.2347 P32.0144 2 NEEDLE BUSH 10 X 14 X 12 A17
N3.3172 P32.0136 3 SLIDE-BEARING 8 X 10 X 10 C3
N3.3172 P32.0153 1 SLIDE-BEARING 8 X 10 X 10 C1
N3.3174 P32.0139 2 SLIDE-BEARING 4 X 5.5 X 6 A8+
N3.3174 P32.2040 1 SLIDE-BEARING 4 X 5.5 X 6 D23
N3.3174 P32.2042 1 SLIDE-BEARING 4 X 5.5 X 6 C20
N3.4509 P32.0156 1 NEEDLE FREE WHEELING 6 X 10 X 15 C14
N3.4520 P32.0150 1 FREE-WHEELING 6 X 10 X 12 B23
N3.4520 P32.0151 1 FREE-WHEELING 6 X 10 X 12 B22
N41.9127 1 ADHESIVE LABEL 20 X 10 X 0.1 C12
N41.9160 P32.0148 2 ADHESIVE LABEL 14.4 VOLT A21+
N43.9142 P32.0147 1 TYPE PLATE <<P324>> A7
N4.9159 1 LABEL <<CE>> C6
N51.2129 P32.2046 1 CONTACT PLUG C22
N51.2129 P32.2048 1 CONTACT PLUG C22
N5.2322 P32.2043 1 MICRO SWITCH D21
N5.2359 P32.2043 1 MICRO SWITCH C20
N5.2702 P32.0148 1 COVER B20
P30.1157 1 GUIDE PIN D10
P30.1163 1 GUIDE PIN D10
[P32.0110] 1 END COVER B6
[P32.0118] P32.0147 1 IDLER STEP B15
[P32.0120] P32.0147 1 WHEEL A14
[P32.0136] 1 TENSIONING BODY D2
[P32.0139] P32.0147 1 SPRING PACKAGE A9
[P32.0140] P32.0147 1 INSERTATION PART B17
[P32.0144] P32.0147 1 ROCKER A17
[P32.0147] 1 BASE MODEL A10+
[P32.0148] P32.0147 1 DRIVE A22
[P32.0149] P32.0148 1 PINION C21
[P32.0150] P32.0148 1 SPUR WHEEL A23
[P32.0151] P32.0148 1 CONICAL GEAR WHEEL C22
[P32.0152] P32.0148 1 MOTOR A23
[P32.0153] P32.0147 1 BODY A2
[P32.0154] P32.0147 1 SPUR WHEEL B13
43.0623.01 P324/12.7/0.40-0.64 P324.0001.01 23.04.07
Item-No. in group Pcs. Description Dimension Field
