Fronius OPT/i WF R Installation Instructions

15
EN
General
Scope of supply (1) Sensor with holder
(2) Connecting cable
(3) This document (not shown)
Prerequisites
Pin assignments
(1)
(1)
NOTE! The OPT/i WF R wire end ring sensor can only be used if an OPT/i ext.
sensor plug has been installed in the respective wirefeeder or SplitBox.
Pin assignment of connecting cable plug:
1. BN = brown
2. Not used
3. BU = blue
4. BK = black
1.
2.
3.
4.
