Fitting the sensor
to the WF
MOUNTING Drum
holder
1
Remove the holder (1) from the sensor
2
Attach the spacer supplied with the wire drum holder
to the underside of the wire drum holder
3
Place the sensor on the spacer as shown
4
Secure the sensor with the two M5 x 12 mm TX25
screws supplied with the wire drum holder
5
Adjust the sensor
6
Set the "Delay"
5
4
1
3
2
(1)
1
1
2
1
3
1
4
2 x TX25
M5 x 12 mm
2
3
4
1
1
5
1
1
6
