General
Functional
principle
The OPT/i WF R wirespool holder wire end sensor constantly monitors the
wirespool. Its integrated sensor detects when the final layer of the wire electrode
has been wound off and outputs a wire end alarm. This alarm does not interrupt
the welding process.
Prerequisites Atttention! The OPT/i WF R wirespool holder wire end sensor can only be used if
an OPT/i ext. sensor plug has been installed in the respective wirefeeder or Split-
Box.
Scope of supply
Safety
WARNING!
Danger from incorrect operation and work that is not carried out properly.
This can result in serious personal injury and damage to property.
▶
All the work and functions described in this document must only be carried
out by technically trained and qualified personnel.
▶
Read and understand this document in full.
▶
Read and understand all safety rules and user documentation for this equip-
ment and all system components.
18
