Push out the ret
aining arm (2) and sensor unit to l
ock in pl
ace
3
Unl
ock the retaining arm (2) by pressing on the cat
ch (3) and ensure that the shoe is touching the
wire el
ectrode
4
5
Fit the wiref
eeding hose between the wirespool hol
der and the wiref
eeder
6
F
eed in the wire elec
trode
7
Close the wir
espool cover (1)
21
EN-US
20
22
