FS0507T PN 60711000162
5.5.2 Charger Specifications: ENW-2413
Charger model ENW-2413
Input voltage Sing phase100V-220V(50/60Hz)
Input voltage 0V(50/60Hz)MA
X7A
Input voltage DC24V
Input voltage MAX13A MAX12A
Battery weight EB100 BPC12-120
5.5.3 Battery charging method
1) Connect the power plug of the charger to a 220V power supply.
"Charging", "Charging completed", and "Abnormal" indicator lights will turn off after
turning on.
2) When charging starts, "Charging" (green) lights up.
3) When charging is completed, "Charging End" (red) lights up. Unplug the power cord
after charging
5.5.4 Tips of battery charging
The proper input voltage of the charger is 85 ~ 132V AC or 170 ~ 264V AC. The charger
automatically switches single-phase 100V • 220V.
5.5.5 Tips for battery charging
1) The machine is deadlocked during charging, the power cannot be turned on, and the
machine cannot be used. When charging is started with the power of this unit turned
