15 Parts Catalog * M/S - Model Specific
Ref.# Part # Description Qty.
1 5TL12733 MAIN FRAME, (DH3474/DH3480/DH3490) 1
5TL13244 MAIN FRAME, (DH3499/DH3409) 1
2 5TL12250 PIVOT SHAFT 2
3 5TL15650 HITCH PIN, CAT. 2 & 3 2
4 5TL10333 ROLL PIN 4
5 5TLVP252 LYNCH PIN 4
6 5TL12735 MAST & PIVOT WELDMENT 1
7 5TL15208 CAT. 2 TOP LINK PIN 1
8 5TLT1001 GANG BEAM, 5"X3"X 63" (DH3474) 2
5TL11686 GANG BEAM, 5"X3"X 72" (DH3480) 2
5TLT1003 GANG BEAM, 5"X3"X 81" (DH3490) 2
5TLT1005 GANG BEAM, 5"X3"X 90" (DH3499) 2
5TLT1007 GANG BEAM, 5"X3"X 99" (DH3409) 2
9 5TL12271 GANG BEAM PIVOT CLAMP 2
10 5TLT727A LOCK NUT, 1 1/2" *MS
11 5TL10727 GANG BEAM BOTTOM CLAMP 2
12 5TL12288 GANG BEAM TOP CLAMP PLATE 2
13 5TLT28 HEX NUT, 1" 4
14 5TL12041 GANG ANGLE ADJUSTING BAR 1
15 5TL9979 HAIR PIN CLIP 5
16 5TL12728 PRESSURE CONTROL ROD, (DH3474/DH3480/DH3490) 1
5TL13247 PRESSURE CONTROL ROD, (DH3499/DH3409) 1
17 5TL12256 PRESSURE CONTROL SCREW 1
18 5TLT509 SPRING, 8 1/2" 2
19 5TLT18 HEX NUT, 1 1/8" 4
20 5TL11975 U-BOLT, 7/8" FOR 5"X3" BEAM *MS
21 5TL12166 TUBULAR GANG HANGER FOR 5"X3" BEAM *MS
22 5TLT21 LOCKWASHER, 7/8" *MS
23 5TLT19 HEX NUT, 7/8" *MS
24 5TL12163 HEX BOLT, 1/2" X 3 1/2" GR. 5 *MS
25 5TL9226 FLANGE LOCK NUT, 1/2" *MS
26 5TLTMDT604IP TRUNNION HOUSING, BEARING, & SNAP RING ASSY. *MS
27 5TL9472 JAM NUT, 1 1/2" *MS
28 5TLT728 LOCKWASHER, 1 1/2" *MS
29 5TLT492 END WASHER, 1 1/2" *MS
30 5TL3242562 DISK BLADE, 24" X 1 1/2"SQ. NOTCHED *MS
31 5TLT103 SPACER SPOOL, 1 1/2" X 9" *MS
33 5TLT495 END SPACER *MS
34 5TLT729 SNAP RING, 4" *MS
35 5TLT604IP BEARING, 1 1/2" SQ. (W211PP3) *MS
