* M/S - Model Specific Parts Catalog 16
Parts List (cont’d)
Ref.# Part # Description Qty.
36 5TLTMD TRUNNION BEARING HOUSING *MS
37 5TLT491 BUMPER WASHER, 1 1/2" *MS
5TLTOR15 OUTRIGGER WASHER, 1 1/2" (REAR GANG ONLY) 1
38 5TL11397 SQUARE AXLE NUT, 1 1/2" *MS
39 5TL9879 AXLE, 1 1/2" X 34 1/8" (DH3480) 2
5TL9880 AXLE, 1 1/2" X 42 3/4" (DH3480) 2
(DH3490) 4
(DH3499) 2
5TL9881 AXLE, 1 1/2" X 51 3/4" (DH3499) 2
(DH3409) 4
5TL9883 AXLE, 1 1/2" X 70 1/2" (DH3474) 2
40 5TL15530 COTTER PIN, 3/16" X 2" 2
41 5TL15652 FRONT PIVOT PIN 1
42 5TLT606 FLATWASHER, 1" 2
43 5TL13311 REAR PIVOT PIN 1
44 5TL15651 CAT. 3 TOP LINK PIN 1
45 5TL15189 ASSEMBLY MANUAL TUBE AND CAP 1
46 5TL15348 SELF TAPPING SCREW, 5/16" X 1" 2
47 5TLT34 LOCKWASHER, 1" 4
48 5TL15376 SPACER WASHER, 1 1/2" SQ. (IF NEEDED) *MS
49 5TL14996 SMV SIGN 1
50 5TL15212 ROUND HEAD MACHINE SCREW, 1/8" X 1/2" GR. 2 2
51 5TL15213 HEX NUT, 1/8" 2
52 5TL14997 SMV MOUNTING BRACKET 1
53 5TL14998 CARRIAGE BOLT, 5/16" X 1" GR. 2 2
54 5TL15198 LOCK NUT, 5/16" 2
55 5TL12034 ANGLE ADJUSTING LEVER 1
56 5TL15194 SAFETY DECAL SHEET 1
5TL15653 "DH3474" MODEL DECAL, NOT SHOWN 2
5TL15654 "DH3480" MODEL DECAL, NOT SHOWN 2
5TL15655 "DH3490" MODEL DECAL, NOT SHOWN 2
5TL15656 "DH3499" MODEL DECAL, NOT SHOWN 2
5TL15657 "DH3409" MODEL DECAL, NOT SHOWN 2
5TL15658 3 1/2" FRONTIER LOGO DECAL, NOT SHOWN 2
5TL15199 9" RED REFLECTOR DECAL, NOT SHOWN 2
5TL15200 9" YELLOW REFLECTOR DECAL (DH3499 & DH3409 ONLY),
NOT SHOWN
2
5TL15659 "DH34" OPERATORS MANUAL, NOT SHOWN 1
