Frontier DH5410C User Manual

1
2
3
4
4
5
5
6
6
7
7
8
9
10
11
11
12
13
14
15
16
16
REF NO
PART NUMBER DESCRIPTION
NO REQ'D
(per Assembly)
1
1
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
5KB501010452
5KB501010453
5KB501010454
5KB501010455
5KB4R60B
5KB4R64A
5KB4N225
5KBNL225
5KBLW075
5KB075175B5
5KB511065282
5KB501040230
5KB125500B8
5KBFW125H
5KBNC125
5KB511016372
5KBLW050
5KB050075B
Axle 2-1/2"dia X 50" (4 Blades)
Axle 2-1/2"dia X 63-1/2" (5 Blades)
Axle 2-1/2"dia X 77" (6 Blades)
Axle 2-1/2"dia X 90-1/2" (7 Blades)
Convex End Washer
Concave End Washer
Hex Nut
Nut Lock
3/4" Lock Washer
3/4" X 1-3/4" UNC Bolt
13" Spacer Spool
Oil-Bath Bearing Assembly
1-1/4" X 5" UNC Bolt
Hardened Flat Washer
1-1/4" Hex Nut
Replaceable Bearing Wear Plate
1/2" Lock Washer
1/2" X 3/4" UNC Bolt
1
1
1
1
1
1
2
2
2
2
1 / 2 / 3 / 4
2
4
8
8
2
8
8
Gang Assembly - Model DH54xxC
16 5KB602040102 1/2" X 30" Notched Disc Blade
38
