22
Machine specifications
DM1160
2. Technical specifications
3. Sound levels
Attachment type 3 point linkage category 1 and 2
Number of disks 6
Working width 2.40 m (7’10’’)
Width in working position 4.30 m (14’1’’)
Height in working position 1.15 m (3’9’’)
Length in working position 2.35 m (7’9’’)
Width in transport position 1.72 m (5’8’’)
Height in transport position 2.95 m (9’8’’)
Length in transport position 2.00 m (6’7’’)
Disk rotational speed 3030 min
-1
PTO speed 540 min
-1
Weight 452 kg (996 lb)
Minimum PTO power requirement 31 kW (42 hp)
Sound levels have been measured in accordance with the measuring methods as defined in:
NF EN ISO 4254-1
«Agricultural machinery - Safety - Part 1: General requirements»
Weighted equivalent continuous acoustic pressure level at the driver's seat (closed cabin) L (A) eq:
Tractor only: 79.3 dB(A)
Tractor + machine: 81.5 dB(A)
