32
Putting into service
DM1160
Uncoupling the machine
From the transport position:
- Remove lynch pin (1) and pin (2).
- Put compensation system in working position using
pin (2) and lynch pin (1).
- Remove R-clip (2).
- Remove transport lock (1).
- Install lock (1) on frame.
- Secure using R-clip (2).
For tractors not fitted with a hydraulic
position control function, unhook check
chain.
The machine must be uncoupled in working
position.
