Optional equipment
47
DM1160
When remounting:
Position conical center of dust seal (3) at the bottom.
Position their largest diameters at right angles to each
other.
Position conical center of spring washer at the top.
Place a wooden wegde (2) between two disks to stop
them from moving.
Tigthen nut (1).
- Torque: 18 daN m (133 lbf ft)
3
1
2
