Frontier ST0726 - Page 55

FRONTIER MODEL ST0726 FACTORY MODEL 626750x16C
55
MTF−051056L
CHUTE ROD
856
855
854
855
861
860
863
864
864
867
Ref. Handle Assy
870
852−5
852−11
852−9
852−8
852−3
868
852−13
852−10
852−1
852−2
852−6
869
Ref. Auger Housing Assy
852−7
852−4
Key No. Part No. Description Key No. Part No. Description
852−1 MT1501533 YZ ASSEMBLY, YOKE & ROD
852−2 MT164x37 SPRING, COMPRESSION
852−3 MT1501067 GEAR, CHUTE ROTATION 9T
852−4 MT17x170 WASHER
852−5 MT579493 PIN, COTTER
852−6 MT1501306E701 BRACKET, GEAR MOUNT
852−7 MT1501293 PIN, HAIR
852−8 MT1501075 YZ ASSEMBLY, YOKE ADAPTER YZ
852−9 MT711682 PIN, HAIR
852−10 MT578060 PIN, UNIVERSAL JOINT
852−11 MT578309 PIN, CLEVIS
852−13 MT578063 HOUSING, UNIVERSAL
854 MT51443 KNOB, SLEEVE
855 MT309312 FLATWASHER
856 MT73664 NUT, PUSH ON 3/8”
860 MT581618 EYE BOLT 3/8−16X6.00
861 MT148 GROMMET, EYE BOLT
863 MT71045 NUT, 3/8−16 HEXJAM
864 MT71072 FLATWASHER .406X.81X.066
867 MT71046 NUT, 3/8−16 HEXNYL
868 MT002X98 BOLT, CARRIAGE 1/4−20 X 1.00
869 MT15X145 NUT
870 MT1501074 YZ CRANK, ASSY CHUTE
