DECAL LOCATION
Your Frontier Carted Rake was manufactured with operator safety in mind. Located on the rake are
various decals to aid in operation, and warn of caution areas. Pay close attention to all decals.
DO NOT REMOVE ANY OF THESE DECALS. IF DECALS ARE LOST, DAMAGED,
OR IF HEAVY DUTY WHEEL RAKE IS REPAINTED, REPLACE DECALS.
REMEMBER: DECALS ARE FOR YOUR PROTECTION AND INFORMATION.
Listed below are the decals on your Carted Rake. These decals may be ordered individually by part
number or by ordering a complete set.
ITEM PART NO. DESCRIPTION
A. 5HP2700A (2) WARNING - Stay Clear of Rake
B. HPFRONTIER13 (2) Frontier Decal
C. 5HP3008WR Frontier Model Decal (WR3008)
5HP3010WR Frontier Model Decal (WR3010)
5HP3012WR Frontier Model Decal (WR3012)
D. 5HP2700B (2) WARNING - Stay Clear of Rake
E. HP2X9RED (2) Red Reflectors
F. HP2X9AMBER (3) Amber Reflectors
G. HP11599 WARNING - Do Not Go Near Leaks
H. HPHS404 Patent Numbers
I. Serial Number
J. HPFRON1 WARNING - Help Avoid Injury
K. 5HP73100A Locking Pin Storage
L. 5HP73100B WARNING - Install Locking Pins
M. 5HP73100C WARNING - Install Locking Pin
N. HP92606 WARNING - Do Not Exceed Transport Speed
O. 5HP51508 DANGER - Avoid Electrical Lines
5HP09083008 Complete Set of Decals (WR3008)
5HP09083010 Complete Set of Decals (WR3010)
5HP09083012 Complete Set of Decals (WR3012)
A
F
D
M
G
B
E L B J K G H I M C E N O
-17-
