FRONTIER WR3008, WR3010, WR3012
CARTED RAKE
Your new Frontier Carted Rake has been manufactured of the finest quality materials and
components. The performance you get from your machine is largely dependent upon how well you
read and understand this manual and apply this knowledge. There is a right and a wrong way to
do everything. Please do not assume that you know how to operate and maintain your Heavy Duty
Wheel Rake before reading this manual carefully. Keep this manual available for ready reference.
SPECIFICATIONS
WR3008 WR3010 WR3012
Number of Wheels. . . . . . . . . . . . . . 8. . . . . . . . . . . . . . . . . . . . . . . 10. . . . . . . . . . . . . . . . . . . . . . . . . 12
Wheel Diameter. . . . . . . . . . . . . . . . 55”. . . . . . . . . . . . . . . . . . . . . 55”. . . . . . . . . . . . . . . . . . . . . . . . 55”
Teeth per Wheel. . . . . . . . . . . . . . . . 40. . . . . . . . . . . . . . . . . . . . . .40. . . . . . . . . . . . . . . . . . . . . . . . .40
Tooth Diameter. . . . . . . . . . . . . . . . . 7mm. . . . . . . . . . . . . . . . . . . .7mm. . . . . . . . . . . . . . . . . . . . . 7mm
Transport Width. . . . . . . . . . . . . . . . 9’6”. . . . . . . . . . . . . . . . . . . . .9’6”. . . . . . . . . . . . . . . . . . . . . .10’6”
Transport Length. . . . . . . . . . . . . . . 13’. . . . . . . . . . . . . . . . . . . . . 15’6”. . . . . . . . . . . . . . . . . . . . . . .18’
Windrow Width Adjustment. . . . . . . 4’-6’. . . . . . . . . . . . . . . . . . . . 4’-6’. . . . . . . . . . . . . . . . . . . . . . 4’-6’
Raking Width. . . . . . . . . . . . . . . . . . 16’-20’. . . . . . . . . . . . . . . . . . 18’-22’. . . . . . . . . . . . . . . . . .20’-24’
3 Settings. . . . . . . . . . . . . . . 3 Settings. . . . . . . . . . . . 3 Settings
Weight. . . . . . . . . . . . . . . . . . . . . . . . 1125 lbs. . . . . . . . . . . . . . . . .1275 lbs. . . . . . . . . . . . . . .1440 lbs.
Number of Transport Wheels. . . . . 2. . . . . . . . . . . . . . . . . . . . . . . 2. . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Center Kicker Wheel. . . . . . . . . . . . N/A. . . . . . . . . . . . . . . . . . . . .Optional. . . . . . . . . . . . . . . .Optional
Rake Wheel Hubs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Tapered Bearings. . . . . . . . . . . . . . . . . . .
Wing Flex. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Limited. . . . . . . . . . . . . . . . . . . . . . .
Hitch Jack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Standard. . . . . . . . . . . . . . . . . . . . . . .
Tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ST175/80D13. . . . . . . . . . . . . . . . . . . .
NOTE:
Determine right or left side of Carted Rake by viewing it from the rear. If instructions or
parts lists call for hardened bolts see page 6 to identify.
