TROUBLE SHOOTING
WARNING
MAKE SURE THAT THE TRACTOR IS SHUT OFF AND THE RAKE CAN NOT MOVE
BEFORE SERVICING THE CARTED RAKE. MAINTENANCE AND REPAIR SERVICE WORK
TO BE PERFORMED BY A QUALIFIED SERVICE PERSON ONLY.
TROUBLE... POSSIBLE CAUSE... POSSIBLE REMEDY...
Rake Lifting Arms Will Not Transport Lock Pins Are In Lock Remove Transport Lock Pins And
Lower Position Place In Storage Position
Hydraulic Coupler Not Coupled Couple Hose To Tractor
To Tractor Properly (See Page #11)
Rake Lifting Arms Hange Up Install Second Hose Kit
And Will Not Lower On Uneven
Terrain
Some Tractors Do Not Operate Install Second Hose Kit
Single Acting Cylinders Well
Rake Lifting Arms Will Not Hydraulic Coupler Not Coupled Couple Hose To Tractor
Raise To Tractor Properly (See Page #11)
Tractor Hydraulics Do Not Tractor Should Have At Least 1500
Sufficient Pressure PSI To Operate Rake
-18-
