FIGURE 1
FRONTIER MODEL WR3008, WR3010 & WR3012
CARTED RAKE
ITEM WR3008 WR3010 WR3012 DESCRIPTION
44. HPT164 “ “ Inner Bearing
* HPT165 “ “ Inner Race
45. HPBFR32 “ “ Rake Wheel Hub
46. HPT170 “ “ Outer Bearing
* HPT171 “ “ Outer Race
47. HPT172 “ “ Nut
48. HPT173 “ “ Hub Cap
49. HPT169 “ “ Cotter Pin
50. HPBFR31 “ “ RH Rake Wheel
* HPT174 “ “ LH Rake Wheel
51. HPT179 “ “ Rake Wheel Center
52. HPT178 “ “ Rake Tooth Clip
53. HPT176 “ “ Rake Wheel Tooth
54. HPT175 “ “ 10mmx25mm Carriage Bolt
55. HPT166 “ “ 10mm Nut
56. HPBFR3 “ “ Jack Handle
57. HPBFR4 “ “ Jack Pin & Chain
58. HP12N14 “ “ Jack Mount
59. HPT168 “ “ 10mmx25mm Bolt
60. HPT166 “ “ 10mm Nut
61. HPT37 “ “ Cotter Pin
62. 5HPCAT195 “ “ 13 x 4-1/2 Wheel
63. 5HPCAT198 “ “ ST175x80D13 Tire
64. HP23N67 “ “ Hose Holder
65. 5HP10WR10 “ “ 3/8”x145” Hose
66. 5HPBFR76 “ “ Hub - Complete
67. 5HP10WR13 “ “ 3” Pin
68. 5HP10WR14 “ “ 5” Pin
69. HP16SV136 “ “ Washer
70. HPBFR70 “ “ Vent Plug
71. HPBFR120 “ “ Orifice
72. HPBFR12 “ “ Male Adapter Union
* HPBFR617 “ “ Adapter Union & Orifice
73. HPBFR33 “ “ Washer
74. HPF56 “ “ Clip Pin
75. 5HPLW55 “ “ Pin
77. 5HP10WR15 “ “ Spring Holder
79. HPT177 “ “ Outer Ring
OPTIONAL DOUBLE ACTING CYLINDER:
76. 5HP10WR10 “ “ 3/8”x145” Hose
78. - - HP23N234 90° Street Elbow
NOTE: #70 Vent Plug Not Used on Double Acting Cylinder
NOTE: * (MEANS NOT SHOWN)
- (MEANS NOT USED ON THIS MODEL)
“ (MEANS SAME PREVIOUS PART NO.)
-23-
