3. INTRODUCTION TO LEADING EDGE SELF RETRACTABLE LIFELINE: Each SRL in this range is constructed in such a way that if

subjected to contact with a sharp edge in the event of a fall from a roof/ terrace etc, the retracted lanyard remains intact, while arresting

the fall immediately.

Conforms for the vertical usage as per ANSI Z 359.14-2014 and Horizontal usage as per ANSI Z 359.14-2014 SRL-LE

Ÿ Connect the end of Lifeline, adjacent to Energy Absorber, to the dorsal attachment of the body support.

Ÿ LE range of SRL's are tested and suitable to be used on edges having radii not greater than 0.005".

4. POSSIBLE USAGE FOR ELECTRON RETRACTABLE FALL ARRESTER:

* It can be used where the Anchorage point is available at foot Level also. (Refer fig 01)

How to Use: Follow below steps to use this equipment as single or double Lanyard. (Refer

fig 02)

STEP 1: Connect the swivel eye of the retractable fall arrester to the dorsal attachment of

the full body harness with the help of special connector PN 170 and PN 169 & ensure the

connector is locked.

STEP 2: Now connect the snap/scaffold hook at the termination end of the device to the

structure and ensure that it is locked. You are now safe to move in normal speed. In the

event of a fall, the Retractable Fall Arrester locks & also minimizes the impact forces on the

body of user.

Similarly, it can be used where the anchorage point is available at foot level by just

connecting the swivel eye of the retractable to the anchorage point and the hook at

termination to the dorsal attachment of harness.

Fig 02

Fig 01

LIST OF RETRIEVAL TYPE LEADING EDGE FALL ARREST SRL's

Model Number

Lifeline Material and Size

RPG25LE
