(Rollers)
(Adjustable Directions)
Max 10” or 255mm
Min 3” or 76mm
(Rollers)
(Notches) (Notches)
(Toggle Plate)
(Secondary Safety Lock)
Component Materials:
Aluminum: Cross Bar, Rollers
Polyester: Webbing
Zinc Plated Steel: Swivel
Stainless Steel: Spring, Hardware
Performance:
Static tensile strength: 5000-lbf
(22kN) minimum
Maximum capacity: One worker
with max weight of 310-lbs.
Weight: 7.7-lbs
Beam ange width range: 3”-10”
Beam ange thickness: 1/4“- 7/8”
Regulatory compliance:
OSHA 1910.66, OSHA 1926.502,
ANSI Z359.18 Type A,
ANSI Z359.7-2011,
EN 795:2012 CE1019
(Toggle Plate)
(Secondary Safety Lock)
(5,000-lbf Swivel)
